Help CenterIntel 10th Core I5-10210U 4.2GHz Turbo NUC PC Motherboard w/ Dual DDR4 2.5G LAN HDMI Thunderbolt3 4K Mini Computer
Related Products
-
Intel 10th Core I7-10510U 4.9GHz Turbo NUC PC Motherboard w/ Dual DDR4 2.5G LAN HDMI Thunderbolt3 4K Mini ComputerUS$ 243 - 275MOQ: 10 Pieces -
Embedded Intel Baytrail J1900 Motherboard for Network Server/Firewall Windows 7/10/Linux PfSense RouterUS$ 55 - 59MOQ: 100 Pieces
-
Embedded Intel Baytrail N3540 Motherboard for Network Server/Firewall Windows 7/10/Linux PfSense RouterUS$ 54 - 58MOQ: 100 Pieces
-
Embedded Intel Atom Processor D525 Motherboard w/ 6 Gigabit LAN for Network Router PC PfSense Firewall GatewayUS$ 45 - 56MOQ: 100 Pieces
-
Intel Gemini Lake J4125 Embedded Motherboard 2.5G 6*LAN for Network PC PfSense Router Windows 7/10/Linux/UbantuUS$ 69 - 88MOQ: 100 Pieces
Spotlight Features
●Soldered down 10th Generation Intel Core i3/i5/i7 Processor，TDP 15W
●Integrated Intel UHD Graphics
●With HDMI2.0，DP，Supports Dual Display
●Dual Channels DDR4，Max.64G/2666MHz
●1*M.2 Key M，Supports 2242/2280 SSD
●1*M.2 Key E，Supports WiFi+BT Module
●1*2.5Gigabit LAN，10/100/1000/2500M Base-Tx Gbe Compatible
●1*Thunderbolt3，Supports Display Port、
Power Delivery、USB3.1Gen2、PCIE device
and docking station
Processor | Intel Comet Lake-U Platform Processor |
Graphics | Intel UHD Graphics |
Display | 1*DP Via Thunderbolt, Max Reslution 5K@60Hz |
1*HDMI2.0, Max Reslution 4096X2160@60Hz | |
Memory | 2*DDR4 SO-DIMM，Max.64GB DDR4/2666MT/s |
Ethernet | 1*Intel i225V 2.5Gbe LAN， Supports WOL、PXE Boot |
Storage | 1*SATA 6Gbps |
1*M.2 Key M，Supports M.2 2242/2280 PCIE X4/SATA SSD | |
Expansion | 1*M.2 Key E，Supports WiFi+BT Module，Support WiFi6 |
Rear Panel I/O | 1*DC_IN |
1*HDMI2.0 | |
1*RJ45 | |
1*Thunderbolt3 | |
2*USB3.1 Gen1 | |
Front Panel I/O | 1*PWR_BTN |
1*USB3.1 Gen1 | |
1*Type-C | |
1*AUDIO Jack，HP_Out/MIC_In 2 in 1 | |
Internal I/O | 1*SATA3.0 6Gbps |
1*SATA_PWR | |
1*F_Panel | |
1*F_USB，2*USB2.0 Ports Via F_USB header | |
1*CPU_FAN | |
1*CLR CMOS
| |
1*M.2 Key M | |
1*M.2 Key E | |
BIOS | AMI UEFI BIOS |
Power Supply | DC 19V |
OS | windows10/11/Linux |
Heat Sink | Smart Fan |
OTR | -10℃～70℃ |
STR | -20℃～85℃ |
Humidity | 5%-95% Relative Humidity,Non-condensing
|
Dimension | 100*100mm |
