Embedded Intel i5 8260U 3.9GHz Turbo Nano EPIC PC Motherboard HDMI 4K Resolution 2.5Gb 4*LAN 6*COM R232 R485
- 10000 Piece / Pieces per Month
- Shenzhen
- T/T L/C PayPal Other
- 10 days
- Embedded Intel Quad Core i7 8565U 4.6GHz Turbo Nano EPIC PC Motherboard HDMI 4K Resolution 2.5Gb 4*LAN 6*COM R232 R485
- Embedded Intel 10th GEN Quad Core i5-10210U 4.2GHz Nano EPIC PC Motherboard HDMI 4K SATA 3.0 4*LAN Gigabit 6*COM R232 R485
- Embedded Intel 10th GEN Quad Core i7 10510U 4.2GHz Nano EPIC PC Motherboard HDMI 4K SATA 3.0 4*LAN Gigabit 6*COM R232 R485
- Intel Celeron J6412/6413 Embedded ITX PC Motherboard 2 Gigabit LAN PfSense Firewall Main Board
- Intel Pentium N6415 Embedded ITX PC Industrial Computer Motherboard 2 Gigabit LAN 2 RJ45 6 COM RS232/485
- Smart Fan Intel Celeron N4000 Dual Core Mini ITX PC Motherboard GPIO HDMI DDR4 Industrial Computer Mainboard
Product Details
Brand Name: | Shineman | Place of Origin: | China | Model Number: | MV4-WCU-4L |
Products Status: | Stock | Application: | Desktop | Graphics Card Type: | Integrated |
Hard Drive Interface: | SATA | Memory Type: | Other, DDR4 | Form Factor: | Other, Nano-4“ |
Chipset Manufacturer: | Intel |
Product Description
Embedded Intel i5 8260U 3.9GHz Turbo Nano EPIC PC Motherboard HDMI 4K Resolution 2.5Gb 4*LAN 6*COM R232 R485
Spotlight Features
●Soldered down 10th/8th Generation Intel Celeron/Pentium/Core i3/i5/i7 Processor
●Integrated Intel UHD Graphics
●With HDMI,LVDS,Supports Dual Display
●Single CHs DDR4,Max.32G/2666MHz
●1*mPCIE,Supports WiFi+BT/4G Module
●1*M.2 Key M,Supports 2242/2280 SSD
●4*Gigabit LAN,10/100/1000 Base-Tx Gbe Compatible,Support POE
●Realtek ALC662 5.1 Channels HDA Codec
●1*16bit programmable GPIO Header
●9V-36V Power supply
Specification
Processor | Intel Whiskey Lake-U/Coffee Lake-U/Comet Lake-U |
Graphics | Intel UHD Graphics |
Display | 1*HDMI1.4, Max Reslution 4096X2304@24Hz |
1*LVDS/eDP(Optional) | |
Memory | 1*DDR4 SO-DIMM,Max.32GB DDR4/2666MT/s |
Ethernet | 4*Intel i211AT Gbe, Supports WOL、PXE Boot |
AUDIO | 1*Realtek ALC662,5.1 CHs HDA Codec,Whit MIC_IN/HP_OUT |
Storage | 1*SATA3.0 |
1*M.2 KEY M,Supports M.2 2242/2280 SATA/NVME SSD | |
Expansion | 1*mPCIE,Supports WiFi+BT/4G Module |
1*SIM Card Slot | |
Rear Panel I/O | 1*DC_IN |
1*PWR_BTN | |
1*HDMI | |
4*USB3.0 | |
4*RJ45 | |
1*AUDIO | |
Internal I/O
| 2*F_USB2.0 Header(4*USB2.0 Via Internal Header) |
1*SATA_PWR | |
1*SATA3.0 | |
1*CLR_CMOS | |
1*AUTO_ON | |
1*GPIO(16bit) | |
6*COM, COM1/COM2 Supports RS232/RS422/RS485 Option | |
1*F_PANEL | |
1*F_AUDIO | |
1*LVDS/1*eDP | |
1*LVDS_PWR | |
1*INVERT | |
1*SPEAKER | |
1*CPU_FAN | |
1*SIM Card Slot | |
BIOS | AMI UEFI BIOS |
Power Supply | DC 9-36V Range |
OS | windows10/11/Linux |
Heat Sink | Fanless |
OTR | -10℃~60℃ |
STR | -20℃~70℃ |
Humidity | 5%-95% Relative Humidity,Non-condensing
|
Dimension | 165*115mm |
