Help CenterOrged Carbon Steel Welding Neck Flange Raised Face ASME B16.5 / EN1092-1
Related Products
-
Forged Carbon Steel WN Flange 1500LB Painted ASME B16.5 Ring Type Joint FaceNegotiableMOQ: 5 Pieces -
6 Inch Forged Stainless Steel Pipe Blind Flanges ASTM A182 F316 ASME B16.5NegotiableMOQ: 5 Pieces
-
A182 F304 / 304L Raised Face Welding Neck Stainless Steel Pipe Flange SCH10S 3 InchNegotiableMOQ: 5 Pieces
-
Annealing and Normalizing Pipe Flanges Painted Black Size From 1/2 Inch To 24 Inch Standard ASME B16.5NegotiableMOQ: 5 Pieces
-
Customized Forged Carbon Steel Flat Face Flange With Non Passing Thread As per the DrwingNegotiableMOQ: 5 Pieces
| Pressure Rating: | 150LB | Wall Thickness: | SCH40 |
| Size: | 2" | Type: | Welding Neck |
| Surface: | Painted Black | Package: | Plywood Pallet Or Cases |
| High Light: | Carbon Steel Forged Welding Neck Flange | ||
| Welding Neck Raised Face Flange | |||
| Welding Neck Flange 150LB | |||
Painted Black Forged Carbon Steel Welding-Neck Flange As per Standard ASME B16.5/EN1092-1 Raised Face
Flanges are used to connect pipes with each other, to valves, to fittings, and to specialty items such as strainers and pressure vessels. A cover plate can be connected to create a "blind flange". Flanges are joined by bolting, and sealing is often completed with the use of gaskets or other methods.
The flange face is the surface area that hosts the gasket. The 6 available types of flange face are flat (FF), raised (RF), ring joint (RTJ), lap joint, male and female (M&F), tongue and groove (T&G). Flanges with different faces require different gaskets and shall never be mated to prevent leakage of the joint. RF and FF flanges may have different types of “finish” (i.e. roughness on top the surface): smooth, stock and serrated.
Flange Applications:
Water works, shipbuilding industry, petrol chemical & gas industry, power industry, valve industry,and general pipes connecting projects etc.
Flange technical parameters:
| Type | weld neck flange, slip on flange, blind flange, tube sheet, threaded flange, socket weld flange, plate flange, spectacle blind, LWN, Orifice flange, anchor flange. |
| OD | 15mm-6000mm. 1/2"to 80".DN10-DN3600 |
| Pressure | 150#-3000#,PN0.6-PN400,5K-40K,API 2000-15000 |
| Standard | ANSI B16.5,ANSI B16.47 A/B, EN1092-1, SABA1123, JIS B2220, ALL DIN, ALL GOST, ALL UNI, AS2129, API 6A , BS4504, etc |
| Wall thickness | SCH5S, SCH10S, SCH10, SCH40S,STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc. |
| Stainless steel | A182F304/304L, A182F316/316L, 316H, 321H,304H, 310H, A182F321, A182F310S, A182F347H, 347L, 317L, A182F316Ti, A182 F317, 904L, 1.4301, 1.4307, 1.4401, 1.4571, 1.4541 etc. |
| Carbon steel | A105, A350 LF1,A350LF2,A350LF3, Q345, E24, A42CP,A48CP, A515 GR55, A515GR60, A515GR70, A516 GR60, A516 GR70, ST37.2,ST45.8, Q235, STEEL20, P235GH,P245GH, P250GH, P265GH, P280GH, P295GP etc. |
| Duplex steel | UNS31803, SAF2205, UNS32205, UNS31500, UNS32750 , UNS32760, 1.4462, 1.4410, 1.4501, A182F51, A182F53 and etc. |
| Pipeline steel | A694 F42, A694F52, A694 F60, A694 F65, A694 F70, A694 F80 etc |
| Nickel alloy | inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H ,C22, C-276, Monel400, Alloy20 etc. |
| Cr-Mo alloy | A182F11, A182F5, A182F22, A182F91, A182F9, 16mo3 etc. |
| Application | Petroleum industry, Refinery Company, fertilizer industry, power station, shipbuilding, onshore platform |
| Attention | ready stock,faster delivery time;available in all sizes,customized;high quality |
