TYPE F Flange Insulation Kit Included G10 With PTFE Gasket For Raised Face Flange

Name: TYPE F Flange Insulation Kit Included G10 With PTFE Gasket For Raised Face Flange
Brand: FLRS
SKU: 171917371

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

FLRS

Place of Origin:

China

Model Number:

FLRS-G022

Shaanxi Flourish Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Xingang

Delivery Detail:

Delivery time depends on order quantity.

Brand Name FLRS

Place of Origin China

Model Number FLRS-G022

Material Fiberglass

Shape Ring Gasket

Standard or Nonstandard Standard

Material:	G10+PTFE/G10/G10/ZPS	Surface:	Zinc Plated For Steel Washer
Delivery Time:	Normally In 10-25 Days	Product Name:	Flange Insulation Kit
Application:	Flange Joints Sealing	Type:	Type E
High Light:	Zinc Plated Spiral Wound Gasket, MOC Spiral Wound Gasket, G10 Spiral Wound Gasket

Factory produced Flange Insulation gasket kit Metal Gasket Ring Spiral Wound Gasket for Steel Flange

Neoprene Faced Plain Phenolic Flange Insulation Gasket Kit

Details:

Neoprene Faced Plain Phenolic Flange Insulation Gasket Kit have been used as standard ''flat'' isolating gaskets in the oil and gas

industries for many years. Soft neoprene rubber sheets are factory applied to both sides of a laminated phenolic retainer providing

an effective sealing surface. The temperature limit of these gaskets is approximately +175o F. (+80o C.)

Gasket Type:

Type E (Full Face Gasket)This gasket kit provides complete protection of both flange faces. The gasket has same outside diameter of

flanges. This feature will prevent collection of foreign matter between the flange faces to ensure complete cathodic isolation.

Type F (Ring Gasket)

This gasket is manufactured to fit only the raised face surface of the flanges. Outside diameter of the gasket is designed to be slightly less

than the inside diameter of the bolt circle. It is recommended that the flanges be wrapped to prevent foreign material from "shorting out"

the flanges.

Item	Insulation Material		Material of Insulation Gasket	Max. Temp.(℃)	Insulation Resistance(Ω)
Item	Sleeve	Washer	Material of Insulation Gasket	Pressure Class (lb)	Insulation Resistance(Ω)
General			PTFE Solid Gasket	-100～100	Over 2.0 x 10¹³
			PTFE Solid Gasket	150	Over 2.0 x 10¹³
			Reinforced PTFE Gasket	-200～200	1.3 x 10¹¹
			Reinforced PTFE Gasket	300	1.3 x 10¹¹
			Neoprene Faced Phenolic Gasket	-30～120	RUBBER	CR 1.6 x 10⁷
	PTFE		Neoprene Faced Phenolic Gasket	150		CR 1.6 x 10⁷
	Epoxy	Epoxy	Glass Reinforced Epoxy Plate Gasket with Rubber O-Ring	-40～150		EPDM 2.0 x 10¹³
	Phenolic	Phenolic	Glass Reinforced Epoxy Plate Gasket with Rubber O-Ring	600		EPDM 2.0 x 10¹³
			Reinforced Phenolic Plate Gasket with Rubber O-ring	-40～150		VITON 9.7 x 10⁹
			Reinforced Phenolic Plate Gasket with Rubber O-ring	600		VITON 9.7 x 10⁹
			Reinforced Phenolic Plate Gasket with Rubber O-ring	-60～150		NBR 1.3 x 10¹¹
			Reinforced Phenolic Plate Gasket with Rubber O-ring	600		NBR 1.3 x 10¹¹
High Pressure	Mica	Mica	Epoxy Faced Metal Plate with Rubber O-ring	150		-
	PTFE	Epoxy	Epoxy Faced Metal Plate with Rubber O-ring	1500		-
	Epoxy	Phenolic	Epoxy faced Metal Plate with PTFE Seal	150	Over 2.0 x 10¹³
	Phenolic		Epoxy faced Metal Plate with PTFE Seal	2500	Over 2.0 x 10¹³
High Temp & Pressure	Mica	Mica	KAMMPROFILE Gasket with STARPITE	1000	9.9 ｘ 10¹⁰
