ECHU Four Core Flat Travel Cable for Lift or Crane

Name: ECHU Four Core Flat Travel Cable for Lift or Crane
Brand: ECHU
Availability: InStock

FOB Price

US$ 0.38 - 6.92 / Meter

300 Meters(Min. Order)

Port Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ECHU	Place of Origin	China
Model Number	YFFB,YFFBG, YFFBP, YFFBPG	Application	Construction
Insulation Material	Rubber	Jacket	Rubber
Conductor Material	Copper

Product Description

As connecting and control cable for cranes and conveyers. It is suitable for the places of railway stations,crane and other related situations.

It is suitable as a control and connection cable for cranes and conveyers on building sites,container goods railway stations and dockyards where operating conditions are rough.

Properties
Sheath: special polychloreprene(Butadiene-acrylonitrile rubber), It remains flexible at -15 °C, Flame resistance and self-extinguishing.

Structure:

Conductor:superfine copper strands acc.to VDE0295,CLASS 5

Insulation:mixed PVC,resistant to oil,flame resistance and self-extinguishing

Colour:acc.to 227IEC(brown,blue,black,green/yellow)

5cores or more with black number with white digital coding
Shielding: Bare Copper Braid.(Individually screen or overall shielding).

Sheath:butadiene-acrylonitrile rubber;resistant to oil,flame retardant and self-extinguishing;

Colour:black(RAL9005)or grey (RAL7001)

Standard:acc.to VDE 0482,part 265-2-1 resp.EN 50265-2-1 and IEC 60332-1.

Technical data:

Rated voltage:≤1.5mm 300/500V >1.5mm:450/750V

Test voltage: ≤1.5mm 2500V >1.5mm:3000V

Mimimum bending radius:0.3m
Burning vertically test:GB/T1 8380.1-2001, IEC 60332-1:1993 test

Passedstandard: GB5023.6,IEC60227-6,EN 50214.

Used under the normal conditions .the temperature of conductor is lower than 70°C

Temperature range:-15°C to +70°C .

Cables are reommended for installations where the suspended length doesn’t exceed 80m;and the speed of travel does not exceed 4m/s

If it is more than this ,with steel

Type	Cores	Spec.
Flat Cable	8	1.25
Flat Cable	10	1.25
Flat Cable	12	1.25
Flat Cable	14	1.25
Flat Cable	20	1.25
Flat Cable	8	1.5
Flat Cable	16	1.5
Flat Cable	18	1.5
Flat Cable	19	1.5
Flat Cable	20	1.5
Flat Cable	21	1.5
Flat Cable	22	1.5
Flat Cable	23	1.5
Flat Cable	24	1.5
Flat Cable	24	1.5
Flat Cable	30	1.5
Flat Cable	36	1.5
Flat Cable	40	1.5
Flat Cable	42	1.5
Flat Cable	48	1.5
Flat Cable	54	1.5
Flat Cable	4	2.5
Flat Cable	4	4
Flat Cable	4	6
Flat Cable	4	10
Flat Cable	4	16
Flat Cable	4	25
Flat Cable	4	35
Flat Cable	4	50
Flat Cable	4	70
Flat Cable	4	95
