Crane Pendant Control Cable RVV(2G) 20x1.5

Pendant Cable :
Special flexibility
Temperature range:-15 to +70°C
Bending radius :20 X outer diameter
one or two steel rope


Applications:
It is the control cable being used for cranes and other appliances in dry or wet enviroment (indoor). For its special flexibility, it also can be used for non-continuous installation or fixation, but cannot work as elevator cables. justed insulated cable rope among cores functions as tensile resistance, there is non-woven fabric to release impact between cores and sheath.

Properties:

In the condition of ultra-height, we recommend to use cable with 2 steels whose broken pulling force reaches 10.4GN and the height 150m. For the adoption of modified PVC sheath,the product has an excellent properties and safty service.

Structure:

Conductor: Fine strands of oxygen-free copper wire. According to VDE0295 CLASS 5.

Color: Various color cores with number Acc.to JISC3306

         Black wit white number and green/yellow acc.to IEC227

Inner liner: non-woven fabric wrapping to release impact

Steel rope: One or two self-supporting steel rope is used to carry tensile force in working.

Outer sheath: special PVC, black (RAL9005)
Rated Voltage:
