Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black Color
E312831 UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black Color
US$ 0.1 - 5.51
MOQ: 305 Meters
Key Specifications
Get Latest Price
Brand Name:
Brand
Place of Origin:
China
Model Number:
UL1283
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
7 days
Related Products
-
E312831 UL Certified ROHS PVC Double Insulation 5AWG 600V UL1283 105℃ Electrical Wire in Yellow/green ColorUS$ 0.11 - 5.51MOQ: 305 Meters -
UL1061 SR-PVC Insulated Copper Wire Electronic Wire & Cable, LED LightUS$ 0.023 - 0.155MOQ: 305 Meters
-
ROHS PVC Electrical Earth Cable UL1015 16AWG 600V With UL CertificateUS$ 0.023 - 0.155MOQ: 305 Meters
-
E312831 UL Certified ROHS PVC Double Insulation 2AWG 600V UL1284 105℃ Electrical Wire in Yellow/green ColorUS$ 0.112 - 10.32MOQ: 305 Meters
-
ROHS PVC Electrical Earth Cable UL1007 300V With UL CertificateUS$ 0.089 - 0.155MOQ: 305 Meters
Brand Name
Brand
Place of Origin
China
Model Number
UL1283
Type
Insulated
Application
Heating
Insulation Material
PVC
Conductor Material
Copper
Conductor Type
Stranded
UL Certified ROHS PVC Double Insulation 6AWG 600V UL1283 105℃ Electrical Wire in Black color
Production description:
UL CERT.:E312831Single Conductor Single Core Flexible Wire UL1283 PVC Insulated 8 AWG,7AWG,6AWG,5AWG,4AWG,3AWG,2AWGConstruction
Conductor :bare copper or tinned copper conductor
Insulation: PVC
Standards
International: UL758 , UL1581
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature:105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
Voltage withstand test:AC 2.5kV/1min
| TYPE | Spec. AWG | Bare Copper | Tinned Copper | Insulation Thickness mm | Weight KG/KM | ||
| Conductor No. | Conductor Dia. | Conductor No. | Conductor Dia. | ||||
| UL1283 | 8 | 118 | 0.3 | 118 | 0.30 | 1.52 | 119.5 |
| UL1283 | 7 | 147 | 0.3 | 147 | 0.30 | 1.52 | 141.8 |
| UL1283 | 6 | 189 | 0.3 | 189 | 0.30 | 1.52 | 173.4 |
| UL1283 | 5 | 238 | 0.3 | 238 | 0.30 | 1.52 | 209.7 |
| UL1283 | 4 | 299 | 0.3 | 299 | 0.30 | 1.52 | 254.3 |
| UL1283 | 3 | 378 | 0.3 | 378 | 0.30 | 1.52 | 311.2 |
| UL1283 | 2 | 475 | 0.3 | 475 | 0.30 | 1.52 | 380.2 |
