high rigid X6325 metal milling machine mini milling machine for metal
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
ram universal milling machine model ZX6350C universal milling machine 5hw with CE for sale
-
bench top milling machine portable milling machine ZX7550ZW with vertical spindle auto-feeding
-
TX68 China horizontal portable milling boring machine with CE
-
TK6411C horizontal fanuc cnc milling boring machine for precise machining
-
TPK611C heavy type horizontal milling boring machine with CE
-
boring milling machine TK611C/4 china heavy horizontal milling boring machine with CE
Product Description
Product Description
X6325 Metal Milling Machine Features:
1. Rectangular guideway on Y and Z axis makes the machine stable and rigid.
2. The guideway on saddle is lined with TF wearable material.
3. Fixed structure is used to connect the mill head without adapter, which makes the cut intensity well.
2. The guideway on saddle is lined with TF wearable material.
3. Fixed structure is used to connect the mill head without adapter, which makes the cut intensity well.
Specificaiton | X6325 |
Table size | 1270×254mm (Optional:1370×254mm) |
T-slotes (No./Width/Pitch) | 3/16/65mm |
Table travel (X/Y/Z) | 850×400×400mm |
Distance between spindle nose and table surface | 60-460mm |
Spindle speed | 66-4540rpm |
Main motor power | 3HP |
Spindle taper | R8 or NT30 |
Travel of spindle sleeve | 127mm |
Arm travel | 400mm |
Feed of spindle sleeve | 0.04/0.08/0.15mm/r |
Milling head rotation | swivel: 45° tiltle: 90° |
Machine overall size (L*W*H) | 1700×1600×2150mm |
N.W | 1200kg |
Detailed Images
Standard accessories:
1. Work light
2. coolant pump
3. machine vice
4. 8pcs/set milling chuck
5. tool box with tools
Optional accessories:
1. 3-axis DRO
2. Oil tray
4. CE electrical part with protection
5. Power feed
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
