Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > China Radial Drilling Machine ZQ3035x10 Manual Type Wide Use Radial Drilling Machine
China Radial Drilling Machine ZQ3035x10 Manual Type Wide Use Radial Drilling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZQ3040 Small Mechanical China Radial Drilling MachineNegotiableMOQ: 1 -
ZQ3040 Mechanical Radial Drilling Machine for Metal WorkingNegotiableMOQ: 1
-
Z5032C Z5040C Z5045C Metal Hole Vertical Drilling MachineNegotiableMOQ: 1
-
Z5045 Multi-functional Vertical Drilling Machine With CE StandardNegotiableMOQ: 1
-
ZQ3050x16 Manual Type Radial Drilling Machine With CertificateNegotiableMOQ: 1
Product Description
Features:
1. Radial drilling machine;
2. Transmission:Mechanical transmission;
3. Max. drilling diameter: 35mm;
4. Spindle taper: Morse 4;
5. Spindle travel: 200mm.
Specification:
Technical parameters |
ZQ3035×10 |
Max Drilling Diameter(mm) |
steel 32 /iron 35 |
Spindle center to column (mm) |
360-900 |
spindle box travel (mm) |
550 |
Spindle nose to table (mm) |
260--1000 |
Spindle travel (mm) |
200 |
Spindle taper(Morse) |
4 |
Spindle speed range (r/min) |
75/130/240/380/660/1200 |
Spindle speeds series(mm/r) |
0.10/0.16/0.25 |
Radial rotation Angle |
360° |
Main motor power( kw) |
2.2 |
Lifting Motor Power ( kw) |
0.75 |
Machine weight (kgs) |
1100 |
Machine overall size (L*W*H mm) |
1550×720×2050 |
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
