M42-I High Precision Swiss Type Cnc Lathe With Cheap Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2021 Hot Selling High Precision CK40L Full-automatic Slant Bed Cnc Lathe Machine for Metal WorkingNegotiableMOQ: 1 -
SGL280 Hot Sales Slant Bed Cnc Lathe Machine From China Factory With CENegotiableMOQ: 1
-
CK0625A Good Rigid CNC Lathe Machine With CENegotiableMOQ: 1
-
Cnc Lathe Machining CK5120 Vertical Lathe Hiot Sale With CENegotiableMOQ: 1
-
CK5120 Single Column CNC Vertical Lathe From China Factory With High PrecisionNegotiableMOQ: 1
Products Description
Machine features of swiss type CNC lathe:
1.Three feeding axes adopt import linear guide rail.
2.Three feeding axes travel in high speed,reduce the idle movement time andincrease the work efficiency.
3.More tools than usual gang type lathe and quicker tool change time. 4.Ideally apply to machine various super slender component.
5.Favorable price,superior performance.
Specification |
M42-I |
Max. bar dia. |
42mm |
Max. spindle hole dia. |
43mm |
lThe height from spindle center to ground |
936mm |
Spindle speed |
0-4000rpm |
Spindle motor power |
5,5kw |
X axis travel |
360mm |
Y axis travel |
360mm |
Z axis travel |
300mm |
X/Y/Z axis motor power |
0.85/0.85/0.85kw |
Slide guideway |
Linear guideway |
Gang tools qty |
16pcs |
Turning tool qty |
5pcs |
Tool size |
16*16mm |
Front drilling tools qty |
4pcs |
Drilling spindle size |
ER20/20mm |
Power tools qty |
7 pcs(4+3) |
Motor power |
2kw |
Rotating speed |
3000rpm |
Collet size |
ER20 |
Drilling hole dia. |
12mm |
Tapping size |
M10 |
Motor Power |
0.12kw |
Capacity |
200L |
Motor power |
25W |
Capacity |
2L |
Input pressure of compressed air |
0.4-0.6Mpa |
Motor Power |
0.75kw |
Hydraulic pressure |
3.0Mpa |
Machine Size(LXWXH) |
2050X1530X1770mm |
Machine Net Weight |
2000kg |
Packing Delivery
Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What’s the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
