Fully Automatic Flash Point by Pensky-Martens Closed Cup Tester
Product Model: JF261Z
The tester adopts the standard ASTM D93 and ISO2719 test methods, and uses microprocessor technology and PID temperature control technology. The heating rate is fast, the temperature is more controlled, and the test results are more accurate. The large LCD screen replaces the redundant design of the original RS232 interface, the operation is simpler and the instrument is more practical. The instrument has a high degree of automation and strong man-machine dialogue capabilities. It has automatic atmospheric pressure correction, automatic lifting, automatic heating, switching, automatic lid opening and ignition, automatic end point detection and automatic printing of test results, automatic air cooling, etc., so that the entire testing process is automated, and the temperature exceeds the limit and automatically stops the detection.
Technical Parameter
1. Display mode: LCD large screen display
2. Display content:
① Control temperature and expected flash point setting temperature.
② Failure prompt screen.
③ Each model parameter and air pressure setting.
3. Measuring range: room temperature～200℃
4. Measurement: 0.1℃
5. Cooling method: forced air cooling
6. Operating temperature: 10～55℃
7. Operating humidity: 30～80%
8. Accuracy: ≤104℃±1℃ ≥104℃±2℃
9. Repeatability: flash point ≤104℃, error ±1℃
Flash point ≥104℃ error ±2℃
10. Electricity source: AC 220V,240V/50,60Hz
11. Power consumption: 380VA
12. Applicable standards: ISO2719 ASTM D93 DIN51751
Main Feature
1. JF261Z is automatically controlled by a microcomputer, and the entire test process and measurement data printing are performed automatically.
2. Large-screen English interface, the screen displays the test temperature, oil product number, test time, etc., and the entire test process is clear at a glance.
3. The micro-printer prints the results, and the cost is low.
4. The temperature is raised by a single-chip microcomputer program to ensure the accuracy of the results.
5. After the experiment, the instrument can be forced to air-cool automatically.
6. The flame size can be adjusted by itself.
7. Automatic lifting system for easy operation.
8. The shell is made of cold-rolled steel plate, and the surface is electroplated and sprayed, which is easy to clean and anti-corrosion.
9. Both manual and automatic operations can be performed during the test (manual or automatic separate test can also be selected).
10. Correction function: correction of current date, time, temperature and current atmospheric pressure.
11. The instrument has a protection program and a self-diagnosis program.
12. The main electrical components of the control department and the measurement department are imported components to ensure the reliability and stability of the instrument.
13. The instrument has a compact structure, small size and beautiful appearance.
14. High degree of automation: Set the flash point parameters according to the operation mode on the LCD screen, press the "Start" button, and the whole test process will be carried out automatically.
