The CI873 is powered from the processor unit through the CEX-Bus, which requires no additional external power source. Follow the steps below to install CI873: 1. Mount the unit onto the DIN-rail. 2. Connect the 100 Mbps Ethernet twisted pair cable to the CH1 connector on the baseplate. 3. Connect the other end of the Ethernet cable to the Fast Ethernet network through the standard Ethernet components.
The ModuleBus has an electrical and a fiber optical interface that are logically the same buses. A maximum of 12 I/O units can be connected to the Electrical ModuleBus and up to seven clusters to the fiber optical ModuleBus. The fiber optical interface is intended for local distribution of I/O clusters and for connection of engineered and standard drives. Figure 40 on page 131 provides details of the fiber optic connectors, together with the PM8xx optical ModuleBus ports.
The ModuleBus for PM891 has a fiber optical interface. The interface is designed for a maximum of seven clusters, of twelve non-redundant or six redundant modules (that is, 7x12 = 84 modules). Redundant and non-redundant modules can be mixed. The fiber-optical interface is intended for local distribution of I/O clusters. . Figure 41 on page 132 provides details of the fiber optic connectors, together with the PM891 optical ModuleBus ports.
The SD83x power supply units (SD831 / SD832 / SD833 / SD834) should be mounted horizontally at a DIN rail. The units have to be used in non-hazardous locations only. The four PSUs have data as follows: – SD831 = Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 Volts regulated @ 3 A. – SD832 = Input a.c. 100-120 or 200-240 V. Output d.c. 24 Volts regulated @ 5 A – SD833 = Input a.c. 100-120 or 200-240 V. Output d.c. 24 Volts regulated @ 10 A – SD834 = Input a.c. 100-240 V or d.c. 110-300 V. Output d.c. 24 Volts regulated @ 20 A Internal primary main fuses are arranged to meet the requirements of electrical safety publications for connection to the Phase - Neutral terminals of primary main network; TN network, 1 (one) fuse. When SD831 and SD834 are used with d.c. input, connect + terminal to L and - terminal to N.
