S800 I/O units via CI854/CI854A and CI801, PROFIBUS DP. Support for HART routing, and hot configuration during run. • S900 I/O units can be connected to PROFIBUS DP. • ABB Drives can be connected to the ModuleBus, via CI801 and also via Modulebus on the PM8xx. Some Drives equipment can be connected directly to PROFIBUS or PROFINET IO. Please refer to Drives-specific documentation for more information. • Genius remote I/O (TRIO) via the CI862 Interface • Satt I/O on ControlNet (19” Satt rack I/O, S200 I/O and S200L I/O) via the CI865 • PROFINET IO via CI871 For more information on supported I/O systems and units, see I/O documentation. ModuleBus The ModuleBus in the AC 800M controller, except PM891, consists of one electrical and one optical unit. The PM891 consists of optical ModuleBus only. The following are the details of the ModuleBus: • Electrical ModuleBus, (see Figure 54 on page 160) – 1 cluster (group), with a maximum of 12 S800 I/O units connected. • Optical ModuleBus (see Figure 54 on page 160) – 7 clusters (groups), with maximum 7 x 12 = 84 S800 I/O units connected. Note that the electrical ModuleBus can only be used for connection of S800 I/O when AC 800M is running in single CPU configuration. PM851/PM851A is restricted to one optical ModuleBus cluster. Use of redundancy will reduce the maximum number of S800 channels. Each cluster may contain up to 12 single S800 I/O units or up to 6 redundant S800 I/O units.
PROFIBUS DP A PROFIBUS DP segment, capable of providing up to 32 nodes, can be directly connected to a PROFIBUS DP Interface unit type CI854A/TP854. This segment can be further extended using repeater units. PROFIBUS PA can be connected to PROFIBUS DP via the PROFIBUS linking device LD 800P, see Appendix C, Recommended Components. For further details refer to PROFIBUS documentation, available at the PROFIBUS Internet site. It is possible to connect the following I/O systems to the PROFIBUS DP: • S800 I/O and/or S800L I/O via FCI – refer to S800 I/O documentation. • S900 I/O via FCI CI920 - refer to S900 I/O documentation. • S200 I/O and/or S200L I/O via Fieldbus Adapter 200-APB12 – refer to S200 I/O documentation. Restrictions apply for PROFIBUS DP. • Other I/O systems can also be connected to PROFIBUS DP. Refer to the relevant manufacturer’s documentation. For further information on the various I/O systems, see specific I/O documentation.
