Brand:EATON
Type:MPB1-TP
Origin: the United States
Warranty: 365 days
Colour: new/used
Shipping method: Courier delivery
Spare parts spare parts, the main DCS control system of PLC system and the robot system spare parts,
Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts
MVI69E-MBS ♦ CompactLogix™ Platform Configuring the Module in RSLogix Modbus Serial Enhanced Communication Module User Manual ProSoft Technology, Inc. Page 18 of 159 Note : The I/O TABLE SIZES above should reflect the Block Transfer Size parameter set in PCB (Section Module Configuration Parameters (page 39)). A Block Transfer Size of 60 uses an I/O TABLE SIZE of 62/61 words. A Block Transfer Size of 120 uses an I/O TABLE SIZE of 122/121 words. A Block Transfer Size of 240 uses an I/O TABLE SIZE of 242/241 words. Applications that require smaller amounts of data or faster update times, such as ControlNet networks, will benefit from smaller block transfer sizes.This procedure is not required if you installed the ProSoft Technology Add-On Profile for this module. 1 Expand the I/O CONFIGURATION folder in the Project tree. Right-click the appropriate communications bus and choose NEW MODULE.
MVI69E-MBS ♦ CompactLogix™ Platform Configuring the Module in RSLogix Modbus Serial Enhanced Communication Module User Manual ProSoft Technology, Inc. Page 20 of 159 3 Set the Module Properties values as follows: Parameter Value Name Enter a module identification string. Example: MVI69EMBS Description Enter a description for the module. Example: ProSoft communication module for Serial Modbus communications. Comm Format Select DATA-INT Slot Enter the slot number in the rack where the MV69E-MBS module is installed. Input Assembly Instance 101 Input Size 62 / 122 / 242 Output Assembly Instance 100 Output Size 61 / 121 / 241 Configuration Assembly Instance 102 Configuration Size 0 The following illustration shows an example where the module was configured for a block transfer size of 60 words (input block size = 62 words, output block size = 61 words): The following options are available: Block Transfer Size Input Block Size Output Block Size 60 62 61 120 122 121 240 242 241
