200KN portable digital Wire Rope Cable Tension Meter

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Specification

ASZ Digital Wire Rope Steel Cable Tension Meter

Function ASZ Rope Tension Testing Instrument can be applied to various occasions, such as power industry, telecommunications industry, transportation industry, glass curtain wall decoration, ropeway industry, construction industry, pleasure grounds, tunnel construction, fishing, major research institutions and teaching institutions, testing institutions and other occasions involved with the tension of ropes and steel wire ropes.

More Pictures

Parameters

model	ASZ-20	ASZ-50	ASZ-100	ASZ-200
maximum load value (KN)	20	50	100	200
Divided load value (KN)	0.01	0.01	0.1	0.1
output connector	Rs232 9-hole socket
power	rechargeable battery charger (charging voltage 100V～240V)
operating temperature	5℃～35℃
transport temperature	-10℃～60℃
relative humidity	15%～80%RH
operation	No vibration focus and corrosive media around
net weight	5kg-7kg
dimensions	650×375×100mm

Select the rope number ranks according to the diameter of tested ropes. Table of Corresponding Rope Number Rank Selection Standard

Measurement range diameter rank	20KN	50KN	100KN	200KN
01	6mm	12mm	20mm	26mm
02	8mm	14mm	22mm	28mm
03	9mm	16mm	24mm	30mm
04	10mm	18mm	26mm	32mm
05	12mm	20mm	28mm	34mm
06	14mm	22mm	30mm	36mm
07	16mm	24mm	32mm	38mm
08	18mm	26mm	34mm	40mm

Packing & Delivery

More Products

Company Profile

FAQ

Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem

Q2:OEM,ODM acceptable or not?
Absolutely Yes

Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...

Q4:Can we visit your factory online?
Absolutely no problem

Q5:Can online video inspection before shipment?
Absolutely no problem

Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem

Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements

Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.

After-sale service:
1. Warranty : 1 year
2. We supply free part for quality problem in warranty
3. Long life technical support and service
