Home > Products > Physical Testing Instruments > 1000N Spring Tester Spring Testing Machine
1000N Spring Tester Spring Testing Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Super Operational Function Nanometer Particle Size Analyzer -DLS Dynamic Light Scattering
-
Laser Diffraction Powder Coating Accurate Particle Size Analyser Ideal For DLS Dynamic Light Scattering
-
Lab 1000N.m Torque Wrench Calibrator Tool Torque Wrench Equipment
-
Mini Mechanical N Kgf Lbf Analog 500N Force Gauge
-
Drinks Wine Beer Water Treatment Portable Turbidity Meter Price
-
Micro Automatic Testing Metal Steel Hardness Tester
Product Description
Product Description
Spring Tester
NTH series of digital spring tension and compression testing machine is to test the tensile, compression spring deformation and load characteristics of the special equipment.
For tensile and compression springs under a certain length of work load test, can also be used for spring, rubber and other elastic device elastic load test.
Parameters
1.high-precision high-resolution: precision 1, the minimum reading of 0.001N;
2.three kinds of display options: real-time, peak, automatic peak;
3. three units of conversion: N, kg, lb
4.the peak to maintain the function: to capture the test peak;
5.the comparison function
6.the automatic peak function: peak hold time (1 to 99 seconds) free to set;
7. automatic shutdown function
Specification
Model Number | NTH-10 | NTH-20 | NTH-30 | ||
Maximum testing load | 10N | 20N | 30N | ||
Minimum resolution | 0.001N | ||||
Diameter of the platen | 34mm | ||||
Maximum free length of measurable spring | 80mm | ||||
Length of travel of the displacement scale | 60mm | ||||
Division value of the Displacement scale | 0.01mm | ||||
Indication error | ±1% | ||||
Power Supply | AC 110-220V, 50HZ-60HZ | ||||
Power Capability (without printer) | 13W | ||||
Power capability (with printer) | 20W | ||||
Working temperature | 20±10℃ | ||||
Temperature of storage and transportation | -27℃～+70℃ | ||||
Relative temperature | 15%～80%RH | ||||
Model Number | NTH- 100 | NTH- 150 | NTH- 200 | NTH- 300 | NTH- 500 | ||||
Maximum testing load | 100N | 150N | 200N | 300N | 500N | ||||
Minimum resolution | 0.01N | ||||||||
Diameter of the platen | 48mm | ||||||||
Maximum free length of measurable spring | 150mm | ||||||||
Length of travel of the displacement scale | 90mm | ||||||||
Division value of the displacement scale | 0.01mm | ||||||||
Indication error | ±1% | ||||||||
Power Supply | AC 110-220V, 50HZ-60HZ | ||||||||
Power capability (without printer) | 13W | ||||||||
Power capability (with printer) | 20W | ||||||||
Working temperature | 20±10℃ | ||||||||
Temperature of storage and transportation | -27℃～+70℃ | ||||||||
Relative temperature | 15%～80%RH | ||||||||
Model Number | NTH-1000 | NTH-2000 | NTH-3000 | NTH-5000 | |||
Maximum testing load | 1000N | 2000N | 3000N | 5000N | |||
Minimum resolution | 0.1N | ||||||
Diameter of the platen | 108mm | ||||||
Maximum free length of measurable spring | 200mm | ||||||
Length of travel of the displacement scale | 150mm | ||||||
Division value of the displacement scale | 0.01mm | ||||||
Indication error | ±1% | ||||||
Power Supply | AC 110-220V, 50HZ-60HZ | ||||||
Power capability (without printer) | 13W | ||||||
Power capability (with printer) | 20W | ||||||
Working temperature | 20±10℃ | ||||||
Temperature of storage and transportation | -27℃～+70℃ | ||||||
Relative temperature | 15%～80%RH | ||||||
More Products
Factory
