10/100/1000M 8 Port Poe Switch

Product

8-PORT 10/100/1000 SWITCH WITH 8-PORT POE

Typ

RB-P5080008

Network Ports

8 10/100/1000Mbps RJ45 PortsAUTO Negotiation/AUTO MDI/MDIX

Power Pin Assignment

Data provided over pairs over 1/2and 3/6 ,Power over spare pairs4/5(+) and 7/8 (-)

PoE Distance

100m

Transmission Method

Store-And-Forward

Network Media

10BASE-T:UTP category 3,4,5 cable (maximum 100m)

100BASE-T:UTP category 5,5e cable (maximum 100m)

100BASE0-TX: UTP category 5, 5e cable (maximum 100m)

Performance Specifications

Bandwidth: 24 Gbps

Network latency:Less than 20 μs for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmission

Buffer memory:8M embedded memory per unit

Address database size:8,000 media access control (MAC) addresses per system

Addressing:48-bit MAC address

Mean Time Between Failure (MTBF):190,000 hours (~ 21 years)

Acoustic Noise: 0 dB

Network Protocol

and Standards

IEEE 802.3i 10BASET

IEEE 802.3u 100BASETX

IEEE 802.3x Flow Control

IEEE 802.1af DTE Power via MDI

IEEE 802.3af

Status LEDs

System: Power, PoE Maximum Power

Per Port: Link, Activity, Speed, PoE Active, PoE Fault

Power Supply

Total Power Consumption: 120 W maximum

PoE Watt budget: 110W

IEEE802.3af Power Consumption: 110 W maximum (Ports 1 – 8)

AC110~265V power input;  plug is localized to country of sale

Physical Specifications

Dimensions (H x W x D):44 x279 x 195mm

Weight:1.25kg

Environmental Specifications

Operating temperature: 0 to 55°C

Storage temperature: -20 to 75°C

Operating humidity: 90% maximum relative humidity, non-condensing

Storage humidity: 95% maximum relative humidity, non-condensing

Operating altitude: 10,000 ft (3,000 m) maximum

Storage altitude: 10,000 ft (3,000 m) maximum

Electromagnetic Emissions

CE mark, commercial

FCC Part 15 Class B

VCCI Class B

EN 55022 (CISPR 22), Class B

Safety

CE Mark ,commercial

CE/LVD EN60950

Warranty

1 years for PoE Switch

2 years for power supply

Package Contents

8-PORT 10/100/1000M SWITCH WITH 8-PORT POE (RB-P5080008)

AC power line

Installation guide

Warranty/Support Information card

Package Contents

8-PORT 10/100/1000M SWITCH WITH 8-PORT POE (RB-P5080008)

AC power line

User manual

Warranty/Support Information card
