High Quality 10/100m 8 Port Poe Switch

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Ordering information

Product :RB-P1090008 Type :9-PORT 10/100M SWITCH WITH 8-PORT POE ,IEEE 802.3af ,

PoE Power Output ：15.4Watts,

PoE Budget:120Watts

Power Pin Assignment :Data provided over pairs over 1/2and 3/6

Power over spare pairs4/5(+) and 7/8 (-)

Package contents	9-port 10/100M SWITCH WITH 8-port POE(RB-P1090008)
		AC adapter
		Installation guide
		Warranty/Support Information card

Product Description

Hot selling 10/100m 8 port poe switch

Description

The 8 port PoE Switch RB-P1090008 provides power and data from a single point,using Power over Ethernet (PoE) over a single Cat-5 cable. The nine Fast Ethernet ports can be used for any 10/100 Mbps link and our of 1-8 port can supply industry-standard IEEE 802.3af power.Advanced auto-sensingal gorithm gives power only to IEEE802.3af end devices, so no need to worry about damaging proprietary PoE or non-PoE equipment.

In addition, it discontinues the power when PoE devices are disconnected.Easy and reliable, the PoE Switch RB-P1090008 automatically determines PoE requirements, speed, duplex, and cable type using Auto Uplink™.

The affordably priced PoE Switch RB-P1090008 delivers PoE to any small business network that wants to simplify the installation of wireless access points and IP-based surveillance cameras. These devices are optimally installed on a ceiling or high on a wall, away from most electrical outlets. PoE eliminates the requirement for a dedicated electrical outlet to power these devices.

This allows for flexibility in situating devices where AC power is difficult to access and lowers installation costs. Compact and flexible, the PoE Switch RB-P1090008 is ideal for small business networks that need to inexpensively use PoE to deploy wireless access points and IP-based network surveillance cameras.

Applications

* Switches,servers and routers

* Data Center networks

* Storage area networks

* High performance computing

* Telecommunication and wireless infrastructure

* Medical diagnostics and networking

* Test and measurement equipment

Main Feature

1. IEEE 802.3af power on up to 8 ports

2. Supply power to wireless access points and surveillance cameras over Cat-5 cabling

3. 9 10/100 Mbps Ports with AutoUplink™

4. Supports PoE power up to 15.4W for each PoE port

5. Supports PoE power up to 105W for all PoE ports

6. Supports PoE IEEE 802.3af compliant PDs

7. Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode

8. 1K entry MAC address table of the PoE Switch RB-P1090008 with auto-learning and auto-aging

9. LED indicators for monitoring power, link, activity and speed
10. External power adapter supply

Target Industries

1. HD monitor transmission and power supply

2. Wireless AP layout transmission and power supply

3. Network telephone transmission , intelligent house and home system

4. Intelligent transportation supervisory system (ITS )

5. High-speed Way supervisory/Tele-Communication System

6. Security protection system, TV medical treatment

7. Long-distance Muti-media Schooling, Campus monitoring

8. Long-distance broadcast television transmission system

9. High-building Security Protection, Military Tele-Com projects

Flexible

Choose to plug in up to nine Ethernet or Fast Ethernet devices and mix in up to four IEEE802.3af IP-based devices like wireless access points or IP-based network surveillance cameras.

Place these IEEE802.3af-compliant devices where they belong – high up on walls and ceiling for maximum coverage –or anywhere else you need them. Power and data are carried over standard Cat 5 cabling

Plug and play

The standards-based PoE Switch RB-P1090008 senses and adjusts for network speed and cabling type automatically, for easy integration into your existing 10/100 Ethernet network. For PoE, the switch automatically detects IEEE802.3af-compliant devices, and supplies power as needed. Front panel LEDs keep you informed of switch and PoE status.

Target industries

1. HD monitor transmission and power supply

2. Wireless AP layout transmission and power supply

3. Network telephone transmission , intelligent house and home system

4. Intelligent transportation supervisory system (ITS )

5. High-speed Way supervisory/Tele-Communication System

6. Security protection system, TV medical treatment

7. Long-distance Muti-media Schooling, Campus monitoring

8. Long-distance broadcast television transmission system

9. High-building Security Protection, Military Tele-Com projects
