        High quality Store-And-Forward poe extender

1. Description

  1. The PoE Switch RB-P1050004F provides power and data from a single point, using Power over Ethernet (PoE) over a single Cat-5 cable. The four RJ45 network ports + one fiber port can be used for any 10/100 Mbps link and four of these ports can supply industry-standard IEEE 802.3af power. Advanced auto-sensing algorithm gives power only to IEEE802.3af end devices, so no need to worry about damaging proprietary PoE or non-PoE equipment.
  2. In addition, it discontinues the power when PoE devices are disconnected. Easy and reliable, the PoE Switch RB-1050004F automatically determines PoE requirements, speed, duplex, and cable type using Auto Uplink™.

2.  Product Features

  1. IEEE 802.3af power on up to 4 ports
  2. Supply power to wireless access points and surveillance cameras over Cat-5 cabling
  3. 5 10/100 Mbps Ports with AutoUplink™
  4. Supports PoE power up to 15.4W for each PoE port
  5. Supports PoE power up to 53W for all PoE ports
  6. Supports PoE IEEE 802.3af compliant PDs
  7. Supports IEEE 802.3x flow control for Full-duplex Mode and back pressure for Half-duplex Mode
  8. 1K entry MAC address table of the PoE Switch RB-P1050004 with auto-learning and auto-aging
  9. LED indicators for monitoring power, link, activity and speed
  10. External power adapter supply

3.   Specifications

poe extender

Product

5-Port 10/100M Switch with 4-Port POE and 1-Port Fiber

Typ

RB-P10500041F

Network Ports

4 10/100Mbps RJ45 Ports AUTO Negotiation/Auto MDI/MDIX

1 100Mbps SC Ports Single-mode optical fiber

Power Pin Assignment

Data provided over pairs over 1/2and 3/6, Power over spare pairs4/5(+) and 7/8(-)

PoE Distance

100m

Transmission Method

Store-And-Forward

Network Media

10BASE-T:UTP category 3,4,5 cable (maximum 100m)

100BASE-T:UTP category 5,5e cable (maximum 100m)

Single-mode optical fiber(Single fiber or double fiber), maximum 25KM

Performance Specifications

Bandwidth:1.6Gbps

Network latency:Less than 20 μs for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmission

Buffer memory:96 KB embedded memory per unit

Address database size:1,000 media access control (MAC) addresses per system

Addressing:48-bit MAC address

Mean Time Between Failure (MTBF):190,000 hours (~ 21 years)

Acoustic Noise: 0 dB

Network Protocol

and Standards

IEEE 802.3i 10BASET

IEEE 802.3u 100BASETX

IEEE 802.3x Flow Control

IEEE 802.1af DTE Power via MDI

IEEE 802.3af

Status LEDs

System: Power, PoE Maximum Power

Per Port: Link, Activity, Speed, PoE Active, PoE Fault

Power Supply

Total Power Consumption: 60 W maximum

PoE Watt budget: 56W

IEEE802.3af Power Consumption: 56 W maximum (Ports 1 – 4)

48VDC, 1.25A power output; plug is localized to country of sale



4. Order Information

Product:RB-P1050004F

Type:5-Port 10/100M Switch with 4-Port POE and 1-Port Fiber,Single-mode fiber double,SC fiber interface ,IEEE 802.3af,PoE Power Output:15.4Watts,PoE Budget:60Watts

Power Pin Assignment:Data provided over pairs over 1/2and 3/6 ,Power over spare pairs4/5(+) and 7/8(-)



5.Accessories in the package

poe extender

Package Contents

5-Port 10/100M Switch with 4-Port POE and 1-Port Fiber(RB-P1050004F)

AC Adapter

Installation guide

Warranty/Support Information card
