High Quality 8/16/24 Port 10/100/1000Mb/s Poe Switch-2 Gigabit SFP Port POE Switch

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

OEM service 8/16/24 port 10/100/1000Mb/s poe switch-2 gigabit SFP port POE Switch

Description

To fulfill the demand of PoE for network applications with Gigabit speed transmission, the ROLLBALL PoE Gigabit Ethernet Switch-RB-P5080008 is an ideal solution. Each 10/100/1000Mbps port of RB-P5080008 features IEEE 802.3af Power over Ethernet (PoE) that combines up to 120 Watts power output and data per port over one Cat.5E / 6 Ethernet cable, with totally 120 Watts PoE budget on whole system

It is designed specifically to satisfy the growing demand of power consuming network PD (powered devices) such as network cameras, wireless LAN access points and other network devices .

Application

1).10GBASE-ER at 10.3125Gbp

2).10GBASE-EW at 9.953Gbps

3).Other Optical Links

4).Data Centers

Features

1.IEEE 802.3af power on up to 8 ports

2.Supply power to wireless access points and surveillance cameras over Cat-5 cabling

3.8 10/100/1000 Mbps Ports with AutoUplink™

4.Supports PoE power up to 15.4W for each PoE port

5.Supports PoE power up to 110W for all PoE ports

6.Supports PoE IEEE 802.3af compliant PDs

7.Hardware based 10/100/1000Mbps Auto-Negotiation and Auto MDI/MDI-X

8.8K entry MAC address table of the PoE Switch RB-P5080008 with auto-learning and auto-aging

9.LED indicators for monitoring power, link, activity and speed

10.External power adapter supply

Specifications

Product	8-PORT 10/100/1000 SWITCH WITH 8-PORT POE
Typ	RB-P5080008
Network Ports	8 10/100/1000Mbps RJ45 PortsAUTO Negotiation/AUTO MDI/MDIX
Power Pin Assignment	Data provided over pairs over 1/2and 3/6 ,Power over spare pairs4/5(+) and 7/8 (-)
PoE Distance	100m
Transmission Method	Store-And-Forward
Network Media	10BASE-T:UTP category 3,4,5 cable (maximum 100m)
		100BASE-T:UTP category 5,5e cable (maximum 100m)
		100BASE0-TX: UTP category 5, 5e cable (maximum 100m)

Performance Specifications	Bandwidth: 24 Gbps
		Network latency:Less than 20 μs for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmission
		Buffer memory:8M embedded memory per unit
		Address database size:8,000 media access control (MAC) addresses per system
		Addressing:48-bit MAC address
		Mean Time Between Failure (MTBF):190,000 hours (~ 21 years)
		Acoustic Noise: 0 dB
Network Protocol and Standards	IEEE 802.3i 10BASET
		IEEE 802.3u 100BASETX
		IEEE 802.3x Flow Control
		IEEE 802.1af DTE Power via MDI
		IEEE 802.3af
Status LEDs	System: Power, PoE Maximum Power
Status LEDs		Per Port: Link, Activity, Speed, PoE Active, PoE Fault
Power Supply	Total Power Consumption: 120 W maximum
		PoE Watt budget: 110W
		IEEE802.3af Power Consumption: 110 W maximum (Ports 1 – 8)
		AC110~265V power input; plug is localized to country of sale
Physical Specifications	Dimensions (H x W x D):44 x279 x 195mm
Physical Specifications		Weight:1.25kg
Environmental Specifications	Operating temperature: 0 to 55°C
		Storage temperature: -20 to 75°C
		Operating humidity: 90% maximum relative humidity, non-condensing
		Storage humidity: 95% maximum relative humidity, non-condensing
		Operating altitude: 10,000 ft (3,000 m) maximum
		Storage altitude: 10,000 ft (3,000 m) maximum
Electromagnetic Emissions	CE mark, commercial
		FCC Part 15 Class B
		VCCI Class B
		EN 55022 (CISPR 22), Class B
Safety	CE Mark ,commercial
Safety		CE/LVD EN60950
Warranty	1 years for PoE Switch
Warranty		2 years for power supply
Package Contents	8-PORT 10/100/1000M SWITCH WITH 8-PORT POE (RB-P5080008)
		AC power line
		Installation guide
		Warranty/Support Information card

Accessories in the package
Package Contents	8-PORT 10/100/1000M SWITCH WITH 8-PORT POE (RB-P5080008)
		AC power line
		User manual
		Warranty/Support Information card
