Reverse Stand-Off Voltage (VR): 5 ~ 250 V
Rated Random Recurring Peak Impulse Power Dissipation (PPPM) (10 / 1000 µs): 200 W
Xiamen SET Electronics Co., Ltd.
● 200 W peak pulse capability at 10/1000 μS waveform, repetition rate (duty cycles):0.01%
● Compatible with industrial standard package SOD-123FL
● Low profile: maximum height of 1.1 mm
● Low inductance, excellent clamping capability
● For surface mounted applications to optimize board space
● High temperature to reflow soldering guaranteed: 260 °C / 40 sec
● Typical failure mode is short from over-specified voltage or current
● Whisker test is conducted based on JEDEC JESD201A per its table 4a and 4c
● IEC-61000-4-2 ESD 30 kV (Air), 30 kV (Contact)
● ESD protection of data lines in accordance with IEC 61000-4-2
● EFT protection of data lines in accordance with IEC 61000-4-4
● Fast response time: typically less than 1.0 ns from 0 Volts to VBR min
● Glass passivated junction
● Built-in strain relief
● Plastic package is flammability rated V-0 per UL 94
● Meet MSL level1, per J-STD-020
● UL Recognized to UL 497B as an Isolated Loop Circuit Protector
● Matte tin lead–free plated
● Pb-free E3 means 2nd level interconnect is Pb-free and the terminal finish material is tin(Sn) (IPC/JEDEC J-STD-609A.01)
● Halogen-free and RoHS compliant
Surface Mount
SMD
● Communication Equipment
● Security & Protection
● Industrial Control Equipment
● Power Supply
● Automotive Electronics
● New Energy
● Lightning Protection
For product quality, our goal is to be industry-leading. We ensure that the quality of the product meets the expected goals from the following process.
Quality Policy.
Qualified Supplier of Raw Materials.
IQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).
Process, Online Inspection and Testing (Function 100% Test).
IPQC (AQL, Dimension, Function, Visual Inspection).
FQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).
Reliability Test (AQL).
OQC (Packaging, Labeling, Quantity Inspection).
Quality Management System (TUV Approved and issued certificate).
SETsafe | SETfuse
SET
TVS SMF(SMD)_SETsafe & SETfuse.pdf
TVS Diodes are used to protect sensitive circuit from high-voltage transients.Their p-n junctions have a larger crosssectional area than those of a normal diode,allowing them to conduct large currents to ground without damage. SETsafe | SETfuse supplies TVS Diodes with peak power ratings from 200 W to 30 kW,and reverse standoff voltages from 5.0 V to 512 V.
SMF series
Xiamen SET Electronics Co., Ltd.
● Bi-directional
● Low clamping and slope resistance
● For automatic pick and place assembly and reflow process to reduce the manufacturing cost and increase the soldering quality compared to axial leads package
● Patent pending package design
● Meet MSL level 1, per J-STD-020, LF Maximum peak of 245 °C
● ESD follow IEC 61000-4-2
● Tube or tape and reel pack options available
● Pb-free E3 means 2nd level interconnect is Pb-free and the terminal finish material is tin (Sn)
● Halogen free and RoHS compliant
Surface Mount
SMD
● Security & Protection
● Industrial Control Equipment
● Power Supply
● Automotive Electronics
● New Energy
● Lightning Protection
For product quality, our goal is to be industry-leading. We ensure that the quality of the product meets the expected goals from the following process.
Quality Policy.
Qualified Supplier of Raw Materials.
IQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).
Process, Online Inspection and Testing (Function 100% Test).
IPQC (AQL, Dimension, Function, Visual Inspection).
FQC (AQL, Dimension, Function, Visual Inspection, RoHS & REACH Test).
Reliability Test (AQL).
OQC (Packaging, Labeling, Quantity Inspection).
Quality Management System (TUV Approved and issued certificate).
SETsafe | SETfuse
SET
TVS SPC3(SMD)_SETsafe & SETfuse.pdf
TVS Diodes are used to protect sensitive circuit from high-voltage transients.Their p-n junctions have a larger crosssectional area than those of a normal diode,allowing them to conduct large currents to ground without damage. SETsafe | SETfuse supplies TVS Diodes with peak power ratings from 200 W to 30 kW,and reverse standoff voltages from 5.0 V to 512 V.
SPC3 series
