Help Center11ax WIFI6 Outdoor Access Point High-Power Gigabit POE Smart Farm Long-distance High Concurrency Router
Related Products
-
802.11AX WIFI6 3600Mbps Outdoor Wieless Access Point Dual Band 2.4&5.8GHz Outdoor POE Router For Farm Outdoor IP67 Waterproof AP RouterUS$ 980 - 1280MOQ: 1 Piece -
802.11AX WIFI6 3600Mbps Outdoor Wieless Access Point Dual Band 2.4&5.8GHz Outdoor POE Router For Farm Outdoor IP67 Waterproof AP RouterUS$ 1180 - 1580MOQ: 1 Piece
-
802.11AX WIFI6 3600Mbps Outdoor Wieless Access Point Dual Band 2.4&5.8GHz Outdoor POE Router For Farm Outdoor IP67 Waterproof AP RouterUS$ 980 - 1280MOQ: 1 Piece
-
802.11AX WIFI6 3600Mbps Outdoor Wieless Access Point Dual Band 2.4&5.8GHz Outdoor POE Router For Farm Outdoor IP67 Waterproof AP RouterUS$ 1180 - 1580MOQ: 1 Piece
-
600Mbps Dual Band 2.4G&5.8G Outdoor CPE AP Router WiFi Signal Hotspot Amplifier Repeater Long Range Wireless PoE Access PointUS$ 165 - 175MOQ: 1 Piece
Hardware: | |||||
Chipset |
IPQ6000+QCA8075+QCN5022+QCN5052 |
||||
Standard |
802.11ax/ac/b/g/n |
||||
Flash |
SPI NOR 8MB (1.8v)+ NAND 128MB |
||||
DDR3L |
512MB |
||||
2.4G Frequency |
2.4GHz - 2.484GHz |
||||
2.4G Wi-Fi standard |
802.11b/g/n/ax |
||||
5.8G Frequency |
5150~5850MHz |
||||
5.8G Wi-Fi Standard |
802.11 a/n/ac/ax |
||||
Interface |
1 * 10/100 /1000 RJ45 WAN Port |
||||
1 * Reset button,press 10 seconds to revert to default setting | |||||
Antenna |
N type antenna connector |
||||
Data Rate |
1800Mbps |
||||
End Users |
160+ |
||||
2.4G RF Power |
≤ 23dBm |
||||
5.8G RF Power |
≤ 23dBm |
||||
2.4G Receive |
802.11b |
11M |
-90dBm |
1M |
-98dBm |
802.11g |
54M |
-77dBm |
6M |
-93dBm |
|
802.11n HT20 |
MCS7 |
-72dBm |
MCS0 |
-92dBm |
|
802.11n HT40 |
MCS7 |
-71dBm |
MCS0 |
-90dBm |
|
802.11ax HT20 |
MCS11 |
-63dBm |
MCS0 |
-93dBm |
|
802.11ax HT40 |
MCS11 |
-60dBm |
MCS0 |
-91dBm |
|
5.8G Receive |
802.11a |
54M |
-77dBm |
6M |
-95dBm |
802.11n HT20 |
MCS7 |
-75dBm |
MCS0 |
-93dBm |
|
802.11n HT40 |
MCS7 |
-72dBm |
MCS0 |
-91dBm |
|
802.11ac HT20 |
MCS7 |
-74dBm |
MCS0 |
-93dBm |
|
802.11ac HT40 |
MCS7 |
-72dBm |
MCS0 |
-91dBm |
|
802.11ac HT80 |
MCS9 |
-62dBm |
MCS0 |
-88dBm |
|
802.11ax HT20 |
MCS11 |
-63dBm |
MCS0 |
-93dBm |
|
802.11ax HT40 |
MCS11 |
-60dBm |
MCS0 |
-90dBm |
|
802.11ax HT80 |
MCS11 |
-56dBm |
MCS0 |
-87dBm |
|
2.4G EVM |
802.11b: ≤-10 dB; 802.11g: ≤-25 dB; 802.11n: ≤-28dB ; 802.11ax: ≤-35 dB |
||||
5G EVM |
802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB; 802.11ax: ≤-35 dB |
||||
PPM |
±20ppm |
||||
PoE |
48V (IEEE 802.3at) |
||||
LED light |
Sys, WAN, LAN |
||||
Power Consumption |
≤ 24W |
||||
Size |
295*231*80MM |
||||
Weight |
3.5KG |
||||
Others: | |||||
Environment |
Operating |
||||
Antenna
Specification (Optional)
Frequency Range |
2.4GHz & 5.8GHz |
Impedance |
50 Ohms nominal |
Gain |
6dBi 8dBi 12dBi 14dBi 17dBi (Optional) |
Radiation |
Omni or Orientation |
Polarization |
Vertical |
Connector |
N-J |
MM Dimension |
¢20*350mm |
