High speed 2600mm chain-stitch quilting machine


SPECIAL FUNCTION :

New Fabric loading design.Easy loading material

Title body design, Easy to operate and maintain

Thread brake detector

Pneumatic air thread cutting system

Operated using high quality sealed bearings that do not need lubrication

Adjustable presser foot lifting mechanism enables you to quilt a broad range of material thickness .

Emergency safety devices

Improved Quilting software control system allows more precise and stable quilting operations.

CAD pattern drawing pattern system allows more precise and stable quilting operations

Machine comes with 100-300 design patterns .

Error problem detection system

Pattern compensation



INNOVATIVE FUNCTION INTRODUCTION :

 Auto adjustable feed rollers allow operator to adjust various type of thickness

Fabric holder transport block ensures that machine operates with more stability and less noise

Sealed fabric rollers allow better control of design pattern .

High speed machine operation and stable control

Heavy duty tracking system for feed in and feed out material



Technical Specification

Size :lengh*width*height :5450*1500*2000mm

Weight :5000kg

Quilt width ::2450mm

Rotation speed : 600-1200rpm

Production speed  :80-280m/h

Needle size :130/21 140/22 160/23 180/24

Needle arrangement :50.8 76.2 127 (76.2 76.2 152.4)

Max horizontal movement :450mm

Needle space : 25.4mm

Voltage :380v /220v ,50HZ/60HZ

Stitch size :2-7mm

Power :10kw

Quilting thickness :


Feature Icon


Applications:

Mattress comforter clothing handbag glove sleeping bag all bed equipment of pattern
