Flow Frequency Convertor Type Transformer Oil Filtration Equipment for Transformer Maintain
ASSEN Flow Frequency Convertor Type Transformer Oil Filtration Equipment for Transformer Maintain is used in repair of power transformers and reactors with voltage up to 110 kV inclusively, and for recondition of transformer oils and also at mineral oil facilities in view of further regeneration.
It equips with a two-stage vacuum pumping speed and advaced dewatering and degassing system, which can effectively remove water, gas and other impurities in the waste transformer oil. Our large-area three-dimensional flashing technology is designed to remove harmful components such as moisture, impurities, and hydrocarbons in oil quickly and efficiently, amd improve the flashpoint and dielectric strength of insulating oil.
Details of Main Parts
Features:
1.Dehydration, degassing, and impurity removal of 110-1100KV main transformer insulation oil.
2.Vacuum drying of 110-1100KV main transformer insulation oil.
3.Enhance the value of breakdown voltage greatly
4.overload stop device
5. low noise oil pumps and friendly to environmental
6. save your human consumption and after treatment, the waste transformer oil can be used as new oil
7. Perfect vacuum degree can ensure the result of treatment
8. reliable, effective and safe to use
Parameters |
Unit |
ZYD-100 |
|
Flow |
L/Hr |
6,000 |
|
Working vacuum |
Mpa |
-0.08 ～ -0.099 |
|
Working Pressure |
Mpa |
≤0.4 |
|
Temperature Range |
℃ |
0 ～ 100 |
|
Power |
380V,3P,50Hz or as need’s |
||
Working hours without Trouble |
Hour |
8000 |
|
Continuous Working Hours |
Hour |
360 |
|
Working Noise |
dB（A） |
75 |
|
Heating Power |
KW |
60 |
|
Total Power |
KW |
75 |
|
Inlet/Outlet |
mm |
Φ40 |
|
Weight |
Kg |
750 |
|
Overall |
Length |
mm |
1980 |
Width |
mm |
1850 |
|
Height |
mm |
1850 |
|
