JD194-BS4I Din Rail Electrical Measuring Single Phase Power Rs485 Current Transmitter
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JD194-BS4I Single Phase ac 4-20ma Output Current TransducerNegotiableMOQ: 1 -
JD194-BS4U Electrical Measuring Analog Output Single Phase ac Voltage TransducerNegotiableMOQ: 1
-
JD194-BS4Q Sfere 3 Phase 3 Wire Reactive Power Transducer SensorNegotiableMOQ: 1
-
JD194-BS4Q Din Rail Transducor Rs485 AC 3phase Reactive Power Data Logger SensorsNegotiableMOQ: 1
-
JD194-BS4H7 3 Phase Digital ac Power Factor Transducer With ModbusNegotiableMOQ: 1
Product Description
Product Name:JD194-BS4I din rail electrical measuring single phase power rs485 current transmitter
Single-phase current, single-phase voltage transmitter mainly measures the current signal and voltage signal, and outputs 1 or 2 analog signals or outputs digital signals. The working power can be taken from the load.Technical parameters
Accuracy | 0.5% | |
Data update rate | 1s | |
current | rated value:AC 1A,5A | |
voltage | rated value:AC 100v,220v,400v etc | |
overload | continuous:2 times of rated value | |
frequency | 45~65HZ | |
Safe power supply | range | AC 80~270V 50/60HZ ,DC 100~350V |
consumption | ≤5VA | |
Analog output | DC 4~20mA,load≤350Ω DC 0~5v，load≥20kΩ | |
Communcation | rs485 port ,modbus-rtu ,2 wire ,up to 9600bps | |
Operating Temperature | -40~70℃ | |
Storage Temperature | -40~85℃ | |
Relative Humidity | ≤93%RH | |
Insulation | ≥2kVAC | |
Altitude | ≤2500m |
Production Process
SMT
AOI Test
Plug-In Mounting
Wave Soldering
Assembling
Inspection
Packing & Delivery
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory located in Jiangyin Jiangsu Province.
Q: Does your company provide customized manufacturing?
A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples ? Is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
