100 Kvar 3 Phase Reactive Power Compensation Capacitor Bank Low Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Voltage Super Capacitor Reactive Power Compensation BankNegotiableMOQ: 1 -
Low Voltage Power Factor Reactive Power Compensation Capacitor BankNegotiableMOQ: 1
-
SFR-M Reactive Compensation Module Low Voltage Power Factor Correction EquipmentNegotiableMOQ: 1
-
SFR-M Low Voltage Dynamic Harmonic Suppression Power Factor Correction EquipmentNegotiableMOQ: 1
-
SVG Reactive Power Auto Compensation Controller Kvar Capacitor Bank Capacitor Aluminum 2 Years AC / Motor 7-15days ElecnovaNegotiableMOQ: 1
Product Description
Product Name: 100 kvar 3 phase reactive power compensation capacitor bank low price
Our Advantages
Product Paramenters
Function |
Specification |
|
Measurement accuracy |
Current |
≤1.0%(5%~120%In) |
Voltage |
≤0.5%(80%~120%Un) |
|
Power |
≤2% |
|
Power factor |
≤0.01 |
|
Switching mode |
Zero cross switching |
|
Compensation operation |
Working voltage |
AC380V±20%, distortion rate ≤5% |
Comsumption |
≤5VA |
|
Max working current |
1.35 X In |
|
Switching inrush current |
≤3 X In |
|
Host protection |
Over voltage |
430V(can be set) |
Under voltage |
300V(can be set) |
|
Harmonic exceeding |
0%~100% |
|
Local protection |
Over current |
0A~100A |
Over temperature |
55 ℃ |
|
Unbalance |
50% |
|
Control setting |
Control parameter |
Target power factor, switching threshold, delay time etc. |
Peripheral unit parameters |
Current transformer ratio |
|
Network interface |
Pluggable data line, internal network protocol |
|
Mechanical installation |
Outline dimension |
W-71.5mm L-370mm, height is a according to different capacity |
Installation dimension |
Distance of installation fixing holes:W-85mm*L-315MM |
|
Weight |
≤6.5kg |
|
Environment temperature |
Working temperature |
-15℃~45℃ |
Storage temperature |
-25℃~55℃ |
|
Altitude |
≤2000m |
|
Standard |
GB/T15575-2008 |
|
Packing & Delivery
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory located in Jiangyin Jiangsu Province.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples ? is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
A: We are factory located in Jiangyin Jiangsu Province.
Q: Does your company provide customized manufacturing?
A: We provide OEM/ODM service to our customers. Our experienced R&D team will give our customer solution in a high efficiency way.
Q: How long is your delivery time?
A: 3-5 working days for the items were in stock, 15-21days for the items out of stock.
Q: Do you provide samples ? is it free or extra ?
A: You need to pay for the sample and cover the freight as well.
Q: What is your terms of payment ?
A: Order amount less than $3000, 100% paid before shipment, order amount more than $3000,30% as deposit, 70% before shipment, or by negotiated for the both parties.
