Liujiang Five axis Epoxy resin glue dispenser equipment

Name: Liujiang Five axis Epoxy resin glue dispenser equipment
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

5 axis dispensing machine

1 new product
2.High efficiency
3.double head
4 Function warranty
5. CE approved

Parameter

Item/Model	L400B	L500B
Number of axes	5	5
Maximum working area (X / Y / Z/A/B)	400 / 400 / 100 mm/360°/360°	500 / 500 / 100 mm/360°/360°
Workpiece payload	10 kg (22.0 lb)	10 kg (22.0 lb)
Tool payload	5 kg (11.0 lb)	5 kg (11.0 lb)
Maximum speed(XY / Z)	500 / 320 mm/sec	500 / 320 mm/sec
Unit weight	80.5 kg (180 lb)	90 kg (190 lb)
Dimensions	850W x 700H x 850D mm	900W x 780H x 860D mm
Drive system	3-phase micro-stepping motor	3-phase micro-stepping motor
Memory capacity	1–99 programs	1–99 programs
	1–9,999 points per program	1–9,999 points per program
Data storage	USB	USB
General purpose I/O	8 inputs / 8 outputs	8 inputs / 8 outputs
Drive method	PTP and CP	PTP and CP
Dispensing controller	External	External
Power supply	Auto-switching	Auto-switching
	AC100–240V, 750 W	AC100–240V, 750 W
Interpolation	3 axes (3D space)	3 axes (3D space)
Repeatability	±0.02 mm	±0.02 mm
Working temperature	10–40° C (50–104° F)	10–40° C (50–104° F)
Teach pendant	Included	Included
Tip detection	Optional	Optional
Heating function	Optional	Optional
Preheat function	Optional	Optional
Five-axis and three-axis two-in-one	Optional	Optional
Approvals	CE	CE

Packaging & Shipping

Packaging Details:Wooden packing

Delivery Time:within 10 days upon receipt of your payment

Company Information

Liujiang 10 years focused on research and development in the field of dispensing and Solder,Lock screw manufacture.

Dongguan Liujiang Automation Co., Ltd. It was founded in 2008, is a specialized in CNC glue dispenser. automatic dispensing machine, electronic product dispensing machines, multi-axis dispensing machine, PCB dispensing machines .Liujiang have granted the certification of CE. It’s a research,development,manufacturing and sales of international high and new technology enterprise. R& D Headoffice is located in Dongguan city, Guangdong province, China. The total area is 1500 square meters, We have advanced R&D center of the engineers and technicians 18 people, 2 modern production workshops , more than 130 staffs.

Contact: Andy
Trade manager:Andy wang

Dongguan Liujiang Automation Co.,Ltd

www.ljzdh.en.china.cn

if you are interested in our products,welcome to contact us and send inquiry.

↓↓↓
