Help CenterLiujiang Five Axis Glue Dispensing Machine With Two Y Axis Rotation For High Frequency Transformer Dispensing
Related Products
-
Three-Axis Desktop Automatic Glue Dispensing Machine Glue Dispenser for IndustryNegotiableMOQ: 1 Set -
Automatic Glue Dispenser/Three Axis Glue Dispensing Machine With Adjustable Glue RobotNegotiableMOQ: 1 Set
-
High Temperature Dispenser Three Axis Glass Automatic Glue Dispensing MachineNegotiableMOQ: 1 Set
-
Large-Capacity UV Dispenser/Three-Axis Hot Melt Glue Dispenser For Mobile PhoneNegotiableMOQ: 1 Set
-
Multi-axis Single-Head Double Y-Type Automatic Glue Dispensing Machine Hotmelt DispenserNegotiableMOQ: 1 Set
| Item/Model | LJ400B | LJ500B |
| Number of axes | 5 | 5 |
| Maximum working area (X / Y / Z/A/B) | 400 / 400 / 100 mm/360°/360° | 500 / 500 / 100 mm/360°/360° |
| Workpiece payload | 10 kg (22.0 lb) | 10 kg (22.0 lb) |
| Tool payload | 5 kg (11.0 lb) | 5 kg (11.0 lb) |
| Maximum speed(XY / Z) | 500 / 320 mm/sec | 500 / 320 mm/sec |
| Unit weight | 80.5 kg (180 lb) | 90 kg (190 lb) |
| Dimensions | 850W x 700H x 850D mm | 900W x 780H x 860D mm |
| Drive system | 3-phase micro-stepping motor | 3-phase micro-stepping motor |
| Memory capacity | 1–99 programs | 1–99 programs |
| 1–9,999 points per program | 1–9,999 points per program | |
| Data storage | USB | USB |
| General purpose I/O | 8 inputs / 8 outputs | 8 inputs / 8 outputs |
| Drive method | PTP and CP | PTP and CP |
| Dispensing controller | External | External |
| Power supply | Auto-switching | Auto-switching |
| AC100–240V, 750 W | AC100–240V, 750 W | |
| Interpolation | 3 axes (3D space) | 3 axes (3D space) |
| Repeatability | ±0.02 mm | ±0.02 mm |
| Working temperature | 10–40° C (50–104° F) | 10–40° C (50–104° F) |
| Teach pendant | Included | Included |
| Tip detection | Optional | Optional |
| Heating function | Optional | Optional |
| Preheat function | Optional | Optional |
| Five-axis and three-axis two-in-one | Optional | Optional |
| Approvals | CE | CE |
1.High Strength equipment fuselage,XYZ vertical degree is high,with 360 degree rotation.
2.Airframe adopt CNC equipment integrated processing,effectively guarantee the verticality of XYZ,improve the machining precision of the equipment.
3.Single machine is easy to operation.installation.
4.Completely do not need to match the external computer can be stand-alone operation.Settings is not only convenient to installl and operate simple.
5.Humanized teching box allows you to easily complete program setting.
6. Collocation of graphic buttons design taching box.allowing you to easily set between fillip to complete any dispensing path set.Copy to be simple and easy to complete all kinds of path matrix.offset modification,correction point.And the super functions such as program transmission between machines.
7.Carefully developed control card let LJ-400B become a real inhibits PTP and CP three-axis circular arc interpolation equipment.
8. Allows you to rest assured use on any non planar 3 d dispensing path .
9. Suitable for all kinds of requirements on adhesive industry.
10. General common UV glue,silicon.Epoxy.Silver glue,red glue,A.B glue.COB black nductive adhesive.thermal aluminum paste.super glue.Such as glue.all can use in LJ-300B devices.
1.One years warranty for the mother board and glue dispensing machine.
2.Life-long maintenance service for the product.
We are capable to manufacture dispensing equipment and liquid dispenser according to customer's drawings or samples. We are insisting on providing top quality products with competitive price. Please feel free to contact us. Welcome your inquiry.
Contact: Andy
Trade manager:Andy wang
Dongguan Liujiang Automation Co.,Ltd
www.ljzdh.en.china.cn
|
if you are interested in our products,welcome to contact us and send inquiry. ↓↓↓ |
