Good Performance Portable Spectrometer for Copper Composition Analysis
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
1993
Annual Export Value:
Above US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheap Horizontal Brass Pipe Continuous Casting MachineNegotiableMOQ: 1 -
China Factory Brass Billet Making Continuous Casting Machine ManufacturerNegotiableMOQ: 1
-
China Factory Brass Billet Making Continuous Casting MachineNegotiableMOQ: 1
-
Copper Rod Horizontal Continuous Making MachineNegotiableMOQ: 1
-
Top Quality of Aluminum Rod Horizontal Continuous Casting Line MachineNegotiableMOQ: 1
Copper composition analyzer
Technical data
- Paschen-Range,Rowland circle optical system
- Grating focal length: 400mm
- Wavelength range: 130–800 nm,160–800 nm,200–800 nm(three size)
- Detector: high performance linear array CCD
- Temperature of optical cell: temperature autocontrol 34℃±0.5℃
- Pixel resolution: 30pm
- Grating groove: 3600 l/mm
- Level 1 spectral dispersion rate: 1.2 nm/mm
- Outside incident window, easy clean and change
- Automatic peak-seeking technique creates excellent shift correction function(accurate to 0.1 pixels)
- Because of improved vacuum technology, it has excellent ultraviolet sensitivity
Characters
- It adopts the world advanced second-generation CCD full spectrum manufacturing technique (the digital technology replaces the old-fashioned bulky photomultiplier electron tube simulation technique). Its channel can be unconstrained.
- It achieves the synchronization of European technique and international spectrometer technique. We are the first domestic manufacturer that can produce vacuum-type CCD full spectrum spectrometer.
- It adopts vacuum-type optical chamber of constant temperature, which is stable, reliable and maintenance-free. It does not adopt the small dual optical chamber design and solves such technical problems as long and short wave elements
- It does not need cost for channel changing and increasing within the range of substrate.
- It is convenient to upgrade multiple substrates and does not need changing or increasing hardware.
- It has excellent data stabilization. The analysis of the same sample at different periods of time can obtain excellent data consistency.
- It is small in size, light in weight and convenient in movement and installation.
- It has high integration density, high reliability and high stability.
- It economizes on electricity and materials. Its energy consumption is only 50% of the common spectrometer.
Optimized sample stage
- Open type sample stage, satisfy the needs of big size samples
- 4mm analytical gap of sample stage
- “Spouted bed electrode” make easy for small sample and complex shape sample
- Low argon gas consumption, no standby traffic when standby
- Customized adapter for heterosexual sample
- No need to change spark stand for different matrix
- lOptimized impurities discharge system
- Strong sample stage made by copper with excellent heat dissipation
Computer and read out system
- Brand computer
- Processor: AMD dual-core 64X2 5200+
- Chip: AMD 690G + AMD SB600
- Internal storage: 1GB DDR 2
- Hard disk: >250 GB
- CD driver: DVD
- Display: 19inches LCD
Data output
- Stored with variety of data form
- Connected with all kinds of standard printing equipment
- Remote data send and transfer via internet
Software system
- Windows 7 operating system
- Chinese and English operational software
- Optional data maintenance programmes
Dimension:
- Floor type 830mm*700mm*1230mm(L*W*H)Weight:120Kg
Power supply:
- AC220 V /50 Hz
- Maximum power 880 W (main machine 350W,vacuum pump 500W,computer 30W)
- Average power 600 W(main machine 350W,vacuum pump 500W,computer 30W)
- Standby power 60W
- 16 A slow-blow fuse
Requirements of Argon gas
- Pure Argon gas, 99.999%, Argon gas reducing valve(specially reducing valve)
- Air pressure>4MPa;
- Transport through copper pipe
Deatail pictures:
Company Introduction
As a professional manufacturer and exporter of metallurgical machinery and euipment, we are specialized in the design, research and developments, manufacture, sales and service of metallurgical casting equipment. Owning the advanced technology and experienced engineer team, we provide professional solutions to the field of metallurgical machinery and equipment.
After more than twenty-year operation, we have formed complete metallurgical equipment supply chains. All of our products conform to the international quality standards and win extremely great reputation in a variety of markets throughout the world. Nowadays, we have cooperated with many well-know domestic and foreign companies as a gold supplier.
Our main products include induction melting furnace, continuous casting machine, rolling mill and other ralated metallurgy and casting equipment.
We sincerely welcome the old and new clients to communicate and negotiate with us. We are willing to work with you hand in hand to develop forward together and creat brilliant future.
