China high power bldc 24v 180W 200w 350W motor
- 100000 Piece / Pieces per Month
- HK or Shenzhen
- T/T Credit Card
- 75*84mm low rpm high torque bldc motor 24v
- CE &ISO Approved High Quality 24V Blower With Brushless Dc Motor
- High Power 1KW 24v Dc Brushless Lawn Mower Motor
- 24v Home Care Respiratory Treatment Brushless Centrifugal Blower
- Customized high power BO6133 brushless dc motor 24v 500w
- High speed 10mm brushless motor micro dc 7.4v
Product Details
Brand Name: | Constar | Place of Origin: | Guangdong, China | Model Number: | BO6133 |
Type: | Micro Motor | Certification: | CE, ROHS | Torque: | 565mNm |
Construction: | Series Wound | Efficiency: | IE 1 | ||
Protect Feature: | Other | Continuous Current(A): | 0.93A | Speed(RPM): | 6400rpm |
Commutation: | Brushless |
Product Description
China high power bldc 24v 180W 200w 350W motor
CONSTAR MICROMOTOR | ||
PRECISION DC CORELESS MOTOR | BRUSHLESS DC MOTOR | SERVO MOTOR |
GEARMOTOR | STEP MOTOR | MINI CORELESS MOTOR |
1. Applications:UAV,industrial automation,etc
2. Operating Environment:-40~+100°C
3. Characteristics :
The following are our standard products, we also provide customized products and service.
Characteristics | |||
-1-22.2 | |||
1 | Voltage | V | 22.2 |
2 | Terminal resistance | Ω | 0.07 |
3 | No-load speed | rpm | 6400 |
4 | No-load current | A | 0.93 |
5 | Nominal torque | mNm | 1040 |
6 | Nominal speed | rpm | 5800 |
7 | Nominal current | A | 32.6 |
8 | Max. output power | W | 1750 |
9 | Max. efficiency | % | 89.4 |
10 | Back-EMF constant | mV/rpm | 3.5 |
11 | Torque constant | mNm/A | 33 |
12 | KV Value | rpm/V | 290 |
4. Options:Lead wires length, shaft length, special coils, gearheads,bearing type, driver,encoder
5,Outline Drawing:
6,Photo:
Customized Motor Solutions:
CONSTAR MICROMOTOR specialize in design, custom and manufacture electric motors,including DC Coreless Motor, Sonic Motor, Brushless DC Motor, Gear Motor, Servo Motor, DC Core Motor and Mini Step Motor.All of them can be fully and easily customized . We committed to offer high quality, high performance, cost effective options to meet customers specific demands. Choosing to customize one of the motors in our Product Categories now!
7.Other Item
Series | Dimension (mm) | Voltage (V) | No-load Speed (rpm) | No-Load Current (mA) | KV Value (rpm/V) | Torque Constant (mNm/A) |
---|---|---|---|---|---|---|
1308ZWW | Φ13*8 | 3.7 | 39000 | 700 | 10500 | 0.85 |
1511ZWW | Φ15*11 | 7.4 | 35000 | 400 | 4700 | 1.97 |
1709ZWW | Φ17*9 | 10 | 26000 | 110 | 2600 | 3.5 |
1814ZWW | Φ18*14 | 6.4 | 18500 | 270 | 2900 | 3.3 |
Φ18*14 | 6.4 | 22000 | 350 | 3440 | 2.7 | |
1816ZWW | Φ18*16 | 7.4 | 12000 | 160 | 1620 | 5.8 |
2010ZWW | Φ20*10 | 10 | 24000 | 110 | 2400 | 3.9 |
2015ZWW | Φ20*15 | 12 | 11300 | 80 | 940 | 9.9 |
2316ZWW | Φ23*16 | 12 | 19500 | 450 | 1625 | 5.8 |
2414ZWW | Φ24*14 | 12 | 6400 | 40 | 530 | 16.7 |
2814ZWW | Φ28*14 | 11.1 | 22000 | 650 | 2000 | 4.8 |
2820ZWW | Φ28*20 | 10.5 | 13500 | 450 | 1290 | 7.4 |
2824ZWW | Φ28*24 | 11.1 | 10200 | 400 | 920 | 10.3 |
2826ZWW | Φ28*26 | 14.8 | 13500 | 550 | 910 | 10.4 |
2828ZWW | Φ28*28 | 14.8 | 13000 | 650 | 880 | 10.8 |
2830ZWW | Φ28*30 | 14.8 | 13300 | 750 | 900 | 10.6 |
2914ZW | Φ29*14 | 24 | 5500 | 100 | 230 | 40 |
2914ZWW | Φ29*14 | 24 | 5500 | 100 | 230 | 40 |
3212ZWW | Φ32*12 | 12 | 22000 | 500 | 1833 | 5.0 |
3216ZWW | Φ32*16 | 12 | 3200 | 500 | 270 | 35 |
3517ZWW | Φ35*17 | 24 | 4450 | 60 | 185 | 50 |
3518ZWW | Φ35*18 | 12 | 10000 | 500 | 830 | 11.3 |
3825ZWW | Φ38*25 | 14.8 | 10400 | 560 | 700 | 13.5 |
3828ZWW | Φ38*28 | 24 | 29000 | 700 | 1200 | 7.8 |
4316ZWW | Φ43*16 | 12 | 4350 | 180 | 360 | 26 |
4321ZWW | Φ43*21 | 24 | 6700 | 200 | 280 | 34 |
4326ZWW | Φ43*26 | 24 | 6100 | 300 | 260 | 37 |
4834ZWW | Φ48*34 | 22.2 | 10400 | 1300 | 470 | 20 |
6133ZWW | Φ61*33 | 22.2 | 6400 | 930 | 290 | 33 |
8724ZWW | Φ87*24 | 36 | 3600 | 200 | 100 | 95 |
