Micro 10mm Planetary Dc GearMotor With Plastic Gear Box
| CONSTAR MICROMOTOR | ||
| | |
| PRECISION DC CORELESS MOTOR | BRUSHLESS DC MOTOR | SERVO MOTOR |
| | |
| GEARMOTOR | STEP MOTOR | MINI CORELESS MOTOR |
Audio and visual products, high-end toys, personal health care products and security equipment
Characteristics:
| -1012F050-2.5 | |||
| 1 | Voltage | V | 2.5 |
| 2 | Terminal resistance | Ω | 3.7 |
| 3 | No-load speed | rpm | 110 |
| 4 | No-load current | mA | 100 |
| 5 | Max torque | mNm | 37.2 |
| 6 | Load torque | mNm | 9.8 |
| 7 | Load speed | rpm | 80 |
| 8 | Load current | mA | 230 |
| 9 | Reduction ratio | 1/171 | |
| 10 | Weight | g | 3.8 |
| 11 | Operating temperature range | ℃ | -10~+70 |
Lead wires length, shaft length, special coils, gearheads
Customized Motor Solutions CONSTAR MICROMOTOR specialize in design, custom and manufacture electric motors,including DC Coreless Motor, Sonic Motor, Brushless DC Motor, Gear Motor, Servo Motor, DC Core Motor and Mini Step Motor.All of them can be fully and easily customized . We committed to offer high quality, high performance, cost effective options to meet customers specific demands. Choosing to customize one of the motors in our Product Categories now! |
| Series | Voltage (V) | Termanal resistence (Ω) | No-load Speed (rpm) | No-Load Current (mA) | Max Torque (mNm) | Reduction Ratio |
|---|---|---|---|---|---|---|
| GH0607F -0609R001-20-3.0 | 3 | 13.7 | 1240 | 45 | 32 | 1/25 |
| GH1007FC-1012F050-2.5 | 2.5 | 3.7 | 110 | 100 | 37.2 | 1/171 |
| GH1007FG-1012F050-2.5 | 2.5 | 3.1 | 110 | 100 | 37.2 | 1/171 |
| GH1007RC-1012F050-2.5 | 2.5 | 3.7 | 110 | 100 | 37.2 | 1/171 |
| GH1208FC-1215F050 -2.5 | 2.5 | 3.5 | 95 | 60 | 68.6 | 1/120 |
| GH1208FC-1215F051 -5.0 | 5 | 17.8 | 88 | 35 | 62.7 | 1/120 |
| GH1208FC-1220R018 -3.0 | 3 | 4 | 105 | 100 | 76.4 | 1/120 |
| GH1208FC-1230R003 -2.5 | 2.5 | 1.2 | 100 | 150 | 166.6 | 1/120 |
| GH1208RC-1230R004 -5.0 | 5 | 7.5 | 86 | 70 | 137.2 | 1/120 |
Micro 10mm Planetary Dc GearMotor With Plastic Gear Box
