DTR2000 Portable Raman Spectrometer
1 Specifications
DTR2000 System | |
Interface |
USB 2.0/LAN |
OS |
Android 4.4.2 |
Battery endurance |
>5 h |
Integration time |
4ms - 120s |
Supply voltage |
DC 19V(+/-5%) |
Operating temperature |
5~40 ℃ |
Operating humidity |
< 95% |
Size (L*W*H) |
30×22.5×13.2 cm3 |
Weight |
7 Kg |
Reliability | |
Spectral stability |
σ/μ < 0.5% (COT 8 hours) |
Temperature stability |
Spectral shift ≤ 1 cm-1 (10-40 ℃) |
Variation of Spectral intensity in 5 ~ 40 ℃ |
<±5% |
Optics Parameter | |
Spectral region |
250-2400 cm-1 |
Spectral resolution |
6 cm-1 |
Signal-to-Noise |
>200:1 (918 cm-1 of Acetonitrile,10s accumulation, 200mW) |
Incidence slit |
50 μm |
Optical system |
f/4 Crossed Symmetrical Czerny-Turner |
Focal length |
98 mm for incidence and output |
Detector | |
Type |
Linear Array Detector |
Detectable range |
200-1100 nm |
Effective pixel |
3648 |
Dynamic range |
1300:1 |
Pixel dimension |
8μm×200μm |
Full well capacity |
100 Ke- |
Sensitivity |
130 Photon @ 400 nm; 60 Photon @ 600 nm |
Exciting Laser | |
Center Wavelength |
785nm (+/-1nm) |
FWHM |
0.1 nm |
Output power |
≥450 mW |
Power stability |
σ/μ <±0.2% |
Raman Probe | |
Working distance |
6 mm |
Rayleigh scattering resistance |
OD>8 |
Numerical Aperture |
0.3 |
Aperture |
7mm |
Product display
