DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China

DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China thumbnail-1
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China thumbnail-2
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China thumbnail-3
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China thumbnail-4
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China thumbnail-5
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China thumbnail-6
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China photo-1
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China photo-2
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China photo-3
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China photo-4
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China photo-5
DU-8800R/DU-8800RS Double Beam Ultraviolet Visible Spectrophotometer China photo-6
US$ 200 - 3,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Drawell
Place of Origin:
Shanghai, China
Model Number:
DU-8800R/DU-8800RS
Contact Supplier Request Quote Chat Now
Shanghai Drawell Scientific Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Drawell
Place of Origin Shanghai, China
Model Number DU-8800R/DU-8800RS
Size 545x468x245mm/635x515x255mm
Weight 19kgs/19kgs
Wavelength Range 190-1100nm, 190-1100nm
Focal Length 190-1100nm



DU-8800R/ DU-8800RS

Split Beam UV/VIS Spectrophotometer

DU-8800R/DU-8800RS spectrophotometer are advanced split beam ratio monitoring optical system. DU-8800R with 1.8nm fixed bandwidth,  DU-8800RS with optional bandwidth. They are suitable for biochemical, pharmaceutical and clinical lab applications.



* Features

Split beam ensure low drift, low noise and Low stray light

High speed MCU, high precision AD, large storage capacity

Large LCD display (320*240 Dots)

1.8nm or variable Bandwidth meet Pharmacopoeia

Data and Curve can be stored in real-time

Online software upgrade capability

Lamps can be turned on/off individually

Easy to change Pri-aligned lamps

Reinforced baseboard and bracket assures durability

* Function:

Photometric

Quantitative(Standard Curve)

WL Scan(Spectrum Scan)

Time Scan(Kinetics)

DNA/Protein Test

Multi-WL Test

System Utility



* Specifications:

Model

DU-8800R

DU-8800RS

Wavelength Range

190-1100nm

Spectral Bandwidth

1.8nm

0.5/1/2/4/5nm Variable

Optical System

Split Beam Ratio Monitoring, Blazed Holographic Grating (1200 lines/mm)

Wavelength Accuracy

±0.3nm

Wavelength Repeatability

≤0.2nm

Wavelength Setting

Auto, Resolution 0.1nm

Photometric Range

0~200%T, -0.3­~3A, 0~9999C

Photometric Accuracy

±0.002A (0~0.5A), ±0.003A (0.5~1A), ±0.3%T (0~100%T)

Photometric Repeatability

≤0.001A (0~0.5A), ≤0.002A (0.5~1A), ≤0.2%T (0~100%T)

Stray Light

≤0.05%T(220/360nm)

Scan Speed

High, Medium, Low.  Max.2000nm/minute

Baseline Flatness

±0.0015A

Stability

±0.002A/h (500nm,0A)

Noise

≤0.2%T/3min (250/500nm,0%T); ≤0.5%T/3min (250/500nm,100%T)

Sample Compartment

Accommodate 5-100mm Pathlength Cuvette

Detector

Silicon Photodiode

Lamps

Tungsten Lamp & Deuterium Lamp (Pre-aligned)

Display

Graphic LCD (128x64 Dots)

Keypad

30-key Alphanumeric Membrance Keypad

Output Port

USB Port & RS232 Port

Printer

Mini Serial Printer; PC Printer

PC Software

PC Scanning Software

Power Requirements

AC 90-250V,50/60Hz

Dimension

545x468x245mm

635x515x255mm

Net Weight / Gross Weight

19kgs / 24kgs

19kgs / 24kgs
