Help CenterDrawell DW-TY-9000 Full Spectrum Direct Reading Spectrometer
Related Products
-
Drawell Direct Reading Spectrometer Used for Metal AnalysisUS$ 10,000 - 35,000MOQ: 1 Piece -
DW-TY-9900 Inductively Coupled Plasma Emission Spectrometer ICP-AESUS$ 18,200 - 36,500MOQ: 1 Piece
-
TY-9900 Inductively Coupled Plasma Spectrometer-ICP OESUS$ 18,200 - 36,500MOQ: 1 Piece
-
TY-9900 Emission ICP Spectrometer , ICP-OESUS$ 18,200 - 36,500MOQ: 1 Piece
-
DW-TY-9900 Inductively Coupled Plasma Emission SpectrometerUS$ 25,000 - 55,000MOQ: 1 Piece
DW-TY-9000 Type Full Spectrum Direct Reading Spectrometer
Ⅰ General principles
The buyer is responsible for providing the conditions and requirements of the site, and meet the requirements of the external installation and other cooperation conditions, the Seller shall provide the equipment and technical services in accordance with the requirements of this agreement. The seller (to ensure full compliance) shall comply with the requirements of the technical specifications, and the analytical instrument shall meet the requirements of the national (or industry) standards.
DW-TY-9000 Full Spectrum Direct Reading Spectrometer, which adopts the international standards of design and manufacturing technology, follows the steps of international spectrum technology and applied the new all digital technology instead of PMT simulation technology. In addition, in order to make this apparatus' best capability, long term stability and repeability, and the lowest sense lines. The design of vacuum optics room and the technology of all digital excitation light source, advanced CCD detector, high-speed data reading system are applied. This machine is available in metal manufacture and processing industries. It's also one of the main testing machine in metal metallurgy. Such as quality monitoring, material grade identification, material research and development.
3.1 Specifications and technical parameters
Item |
Index |
Detection of substrate |
Fe,Al,Cu,Ni,Ti,Co,Zn,Sn,Mg,Pb etc |
Testing time |
According to the sample type, generally about 25s |
Optical system |
The Paschen Runge construction full vaccum type optics system |
Wavelength coverage |
130~800nm |
Focal length |
400mm |
Detector |
High-performance CCD Array |
Electrode |
Tungsten material injection electrode |
Analytical gap |
The sample analysis of clearance: 3.4mm |
Operating temperature |
(10~35)℃ |
Storage temperature |
(0~45)℃ |
Operating humidity |
20%~80% |
Argon purity requirements |
99.999% |
Argon gas inlet pressure |
0.5MPa |
Argon flow |
Stimulate the flow around 3.5L/min,Maintain flow around 0.4L/min |
Stimulate the maximum power |
400VA |
Type of Lamp-house |
New digital adjustable light, high energy precombustion technology(HEPS) |
Discharge frequency |
100-1000 Hz |
Discharge current |
Maximum 400A |
Excitation aperture |
13mm |
Vacuum system |
The vacuum automatic control and monitoring software |
Working power supply |
220V AC, 50/60Hz, single phase power supply for protective grounding |
Instrument size |
725*865*550(mm) |
Instrument weight |
80kg |
. Elements and the scope of instrumental analysis
Program |
Fe-Low alloy |
Fe-Cr-Ni steel Cr-Ni |
||
Elements |
Min |
Max |
Min |
Max |
C |
0.006 |
1.3 |
0.008 |
2.5 |
Si |
0.01 |
3.9 |
0.09 |
4 |
Mn |
0.03 |
2.1 |
0.12 |
16 |
P |
0.002 |
0.12 |
0.003 |
0.3 |
S |
0.002 |
0.16 |
0.001 |
0.4 |
Cr |
0.01 |
4.5 |
7.4 |
32 |
Ni |
0.004 |
4.4 |
0.8 |
48 |
Mo |
0.004 |
1.3 |
0.08 |
4.2 |
Al |
0.003 |
1.5 |
0.005 |
1.7 |
Cu |
0.002 |
0.5 |
0.05 |
4.5 |
Co |
0.001 |
0.5 |
0.008 |
17 |
Ti |
0.002 |
1.2 |
0.005 |
1.1 |
Nb |
0.002 |
0.3 |
0.02 |
2 |
V |
0.003 |
0.9 |
0.02 |
9.5 |
W |
0.03 |
2.1 |
0.002 |
4.1 |
Pb |
0.003 |
0.03 |
0.001 |
0.02 |
Mg |
0.001 |
0.14 |
0.001 |
0.14 |
B |
0.006 |
0.02 |
0.007 |
0.02 |
Sn |
0.001 |
0.09 |
0.003 |
0.05 |
Zn |
0.002 |
0.04 |
0.006 |
0.08 |
Sb |
0.002 |
0.02 |
0.0005 |
0.022 |
Fe |
(Remain) |
(Remain) |
||
