Blue Laser module at 473nm laser
APPLICATIONS:
All solid state 473nm blue laser is made features of ultra compact, long lifetime, cost -effectiveness and easy operating, which is used in fluorescence sensors, Raman spectrum, laser printing, holography, laser display, submarine communication, biomedicine, laser lighting show, etc.
SPECIFICATIONS:
Central wavelength (nm) | 473±1 | ||
Operating mode | CW | ||
Output power (mW) | >1,5,10, … , 100 | ||
Power stability (rms, over 4 hours) | <3%, <5%, <10% | ||
Transverse mode | TEM00 | ||
M2 factor | <1.2 | ||
Beam diameter at the aperture 1/e2 (mm) | ~1.2 | ||
Beam divergence, full angle (mrad) | <1. 5 | ||
Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) | ||
Noise of amplitude (rms, 1~20MHz) | ~30% | ||
Warm-up time (minutes) | <10 | ||
Beam height from base plate (mm) | 24. 8 | ||
Operating temperature (℃) | 10~35 | ||
Power supply (90-264VAC or 5VDC) | PSU-III-LED | PSU-III-FDA | PSU-III-OEM-97 |
Modulation option | TTL on/off, 1Hz-1KHz, 1KHz-10KHz, 10KHz-30KHz; and Analog modulation option | ||
Expected lifetime (hours) | 10000 | ||
Warranty period | 1 year | ||
Laser Head
PSU-III-LCD Powwer supply
PSU-III-LED Power supply
PSU-III-FDA Power supply
PSU-III-OEM Power supply
Company Information
Changchun New Industries (CNI) founded in 1996, located in Changchun, CHINA, is a leading manufacturer of solid-state and diode laser systems. Our products include green laser, blue laser, yellow laser, red laser, RGB laser, infrared laser, UV laser, single longitudinal mode laser and Q-switched laser systems. CNI lasers are featured with high performance, low cost and excellent laser beam quality, which are specifically designed for OEM, scientific, industrial and instrumentation use. In addition, CNI lasers are ISO-9001, FDA, CE, RoHS and JQA certified.
CNI also provides laser components and accessories, we aim to offer customers complete laser solutions for all solid state lasers, diode lasers, laser marking system with our most convenient and rapid service.
