Specifications
2) protection against hazardous gases by detecting wide range of combustible gases
CO Detector
The Aero sense IR-5500 provides an effective solution for protection against hazardous gases by detecting wide range of combustible gases and CO2 simultaneously.
FEATURES:
Higher accuracy and better lifetime achieved using NDIR sensor Technology..
Optimized for detection of smallest leak of combustible gases and Carbon Dioxide.
Highly resistant to poisoning and etching.
Capable of detecting down to PPM, %LEL, %V/V, mg/m3.
Auto ranging of Gas Concentration from PPM to %V/V & %LEL.
Digital Alphanumeric display with Auto backlit.
Standard 4-20mA signal output proportional to Gas concentration range.
Easy handling and programming with 3 keys.
Can be programmed using Remote Control from 10 meters line of site distance.
Non - Intrusive programming for Flameproof models using Magnetic pen.
Password protected programming menu.
One man Auto software Gas calibration.
Optional alarm relay contacts with two configurable alarm levels.
Optional RS-485 communication port with MODBUS RTU Protocol.
APPLICATIONS:
- Biogas.
- Oil Wells.
- Breweries.
- Steel Plants.
- Gas Turbines.
- Leak detection.
- Chemical Industries.
- Pulp & Paper Industry.
- Fuel Loading Facilities.
- Plant growth Monitoring.
- Pharmaceutical Industries
- Waste water treatment plants
- Cleaning & Solvent extracting.
- Storage areas for food ripening.
- HVAC for better ambient monitoring
- LNG / LPG Processing & storage facilities.
- Parking Areas for safety and environmental issues.
| TECHNICAL SPECIFICATIONS: | ||||||||||
| General | Output Signal | |||||||||
| Detection Method | NDIR, IR Absorption, Dual wavelength multipath. | Standard | 4-20mA Current output proportional to Gas Concentration. | |||||||
| IR Source | Tungsten filament light bulb, pulsated at 4Hz. | Optional | Two SPDT Relays of rating “120VAC/2A, 24VDC/2A”. | |||||||
| Gases Detected | Hydrocarbons (Please select from the list below) & Carbon Dioxide. | Optional | RS-485 Communication port with MODBUS RTU protocol | |||||||
| Display | 8 x 2 Alphanumeric LCD with Auto Backlit. 8 LEDs to indicate status of instrument. | Error Monitoring | ||||||||
| Control Action | i) Two independent Alarm set points with Latch & Non-latch facility. ii) User selectable Hysteresis and Logic option. | i) During Sensor break / open, the Display shows ‘SENSOR OPEN' 4-20mA output goes down to 3.7mA. ii) During Over range, the Display shows ‘OVER RANGE’& 4-20mA output goes up to 21mA | ||||||||
| Setting | By 3 Keys on front panel By using Magnetic pen (Only for Flameproof model) By using Remote Control (Optional) |
| ||||||||
| Auto Ranging | From PPM to % LEL, PPM to %V/V. |
| ||||||||
| Performance | Environmental | |||||||||
| Accuracy | +/- 2% of Full Scale. | Storage Temperature | -40 to +80°C±5% | |||||||
| Response Time | T20 < 5 Seconds T50 < 9 Seconds. T90 < 25 Seconds. | Operating Temperature
| -30 to +70°C±5% | |||||||
| Start-up Time | Less than 30 Seconds. | Humidity | 95% Non-Condensing. | |||||||
| Electrical | Accessories | |||||||||
| Power Supply Power Consumption Connection | 24 VDC, Range 18-36 VDC. Less than 3.2Watts.
3Wires (1.5 mm ) Flexible or Armored Shielded Cable. | CE certified 24 VDC Power supply. Canopy Mounting stand. SCADA Software. RS-485 to USB convertor | RS-232 to RS-485 convertor Hooter Cum Flasher. Gas Calibration Kit. Remote Control. | |||||||
| Weatherproof Housing | Flameproof Housing | |||||||||
| Protection Class | IP-65 | Protection Class | IP-65 for Gas Gr. IIA, IIB & IIC CMRI approved enclosure, CCOE(Optional). | |||||||
| Cabinet Material | Polycarbonate, grey colour | Cabinet Material | Cast Aluminium alloy, LM-6 | |||||||
| Cable Entry | Thermoplastic cable gland (IP 68) | Cable Entry | Double compression cable gland (Ex-Proof), ¾” ET-type | |||||||
| Dimension | 171 mm (H) x 83 mm (W) x 57mm (D) | Dimension | 180 mm (H) x 242 mm (W) x 128mm (D) | |||||||
| Mounting | Wall Mounting / Stand Mounting / Pipe Mounting | Mounting | Wall Mounting / Stand Mounting / Pipe mounting | |||||||
| Weight | Approx 350 Grams. | |||||||||
| Packaging Details: | As per buyers specifications |
|---|---|
| Delivery Detail: | 1 week. |
You can find product information in our website , if you want to know more , please send message to us , we will reply to you all required information.
| Accuracy | +/- 2% of Full Scale. |
| IR Source | Tungsten filament light bulb, pulsated at 4Hz. |
| Gases Detected | Hydrocarbons & Carbon Dioxide. |
