1.The brief introduction of small civil fully automatic electric well drilling machine
a.The small civil fully automatic electric well drilling machine is a new and practical new type of civil drilling machine, which is developed, updated and manufactured on the basis of long well drilling practice based on different types of drilling technology and equipment. The machine is easy to install, simple, labor-saving and easy to operate. It can be operated by two people, with less investment, quick results and high profits. The cost can be recovered in a month, and benefits can be seen in two months. The road has been expanded for the rich farmers in the well.
b.Generally, mortar stones, weathered stones and small pebbles can be played. Diamond bits can be used for granite. The drilling speed is about 50 meters per hour in general geology. Opened 8 centimeters, played 180 meters, 10 centimeters played 160 meters
2 .The main characteristics of small civil fully automatic electric well drilling machine
a.The small civil fully automatic electric well drilling machine occupies a small area (1 square meters), and the quality is light. It moves 2 meters to 3.5 meters, and it can be installed outside the house. After dismantling, the total length is less than 2 meters, and the heaviest part is no more than 40 kilograms. The small tricycle can swim in the countryside.
b.The drill pipe bit can be replaced by 1 inch, 1.5 inch, 4 inch, different caliber plastic pipe and PVC pipe deep well. The average speed of the plain area is 30 meters per hour. The deepest is 180 meters, the well pipe is completely closed, the shallow water layer has no leakage, and drinking is safe and hygienic.
c.The prospecting machine bit has strong rock breaking ability, and the drill bit is durable and not worn. The drill pipe degree of zinc anticorrosion, not rusty.
e.Research and development alone will solve the difficult problem that the upper shaft is easy to unload well. The lifting, unloading and drilling pipes are all mechanized, saving labor, convenient installation, and easy operation. Civilian 220 volt voltage, 60 VOLTS, safe DC power supply, safety is guaranteed.
f.The lifting device is set up by electric and manual dual-purpose, even if the power is suddenly cut off. You can also cope with it.
3.The technical parameter of small civil fully automatic electric well drilling machine
|
Maximum drilling depth (currently verified) |
Open hole 100mm， Deep drilling 160m； Open hole 220mm，Deep drilling 80m； Open hole 300mm，Deep drilling 30m。 |
Pump pressure adaption to drilling depth |
120m |
Input voltage |
220V |
Maximum opening diameter of drilling |
250~300mm |
Total configuration power |
4.55KW |
Drive motor power |
1.25KW |
Improve motor power |
1.1KW |
Maximum lifting weight |
750KG |
Motor power of submersible pump |
2.2KW（lift 46m， flow 12m³/h） |
Drive the rotary speed of the drill rod |
150r/min（No load） |
Floor area of worktable |
1㎡ |
Maximum height of derrick |
3.5m |
Maximum weight of single piece after decomposition |
less than 40KG |
Maximum length of single piece after decomposition |
2m |
Consignment box volume 1 |
1100*450*450mm |
Consignment box volume 2 |
670*670*450mm |
Whole machine weight (without drill rod) |
200KG |
Drill rod specification |
diameter 42mm：2m /root，5.5kg/root |
Operator number |
two people |
