.4 core copper rubber cable With following features
4 core copper rubber cable is produced against IEC60502 and IEC60331, . And the product can be produced against the standard of BS, DN, and the standard required by the clients.
1. The long-term permissible operation temperature of the conductor shall not be higher than 70 degree 2. The max temperature of the conductor of cable should less then 160 when short circuit. (less then 5 second) 3. The cable is not limited by drop in level when being laid, and the environment temperature shall not be lower than 0 degree
4 core copper rubber cable Include following code and specification
Nominal sectional area mm 2 |
Conductor No/Dia. mm |
Nominal Insulated thick mm |
Max overall Dia. mm |
Condcutor Resistance at 20 |
Min insulated resistance at 70MΩ/km |
Weight Kg/km |
2.5 |
9/0.41 |
0.8 |
4.2 |
7.41 |
0.011 |
33.0 |
4 |
19/0.52 |
0.8 |
4.8 |
4.61 |
0.009 |
48.0 |
6 |
19/0.64 |
0.8 |
5.6 |
3.08 |
0.0084 |
68.0 |
10 |
49/0.52 |
1.0 |
7.6 |
1.83 |
0.0072 |
115.0 |
16 |
49/0.64 |
1.0 |
8.8 |
1.15 |
0.0062 |
176.0 |
25 |
98/0.58 |
1.2 |
11.0 |
0.727 |
0.0058 |
272.0 |
MOQ, Capacity& Payment method
For electric wire, aerial cable and power cable, the Minimum Order Quantity is 1000 meters each type. The capacity is 20 kilometers per day.
For electric conductor(AAC,ACSR,AAAC,AASC) for transmission line, the Minimum Order Quantity is 1 ton each type. The capacity is 50 tons per day.
Our payment term is 30% deposit in advance, 70% rest against copy of B/L; or 100% irrevocable L/C at sight
