Specifications
power cable is used as power distribution and transimission line at raced voltage 0.6/1kv which can be fixed installed
power cable with PVC insulation:
1) The long-term working tempeture of cable should be not higher than 70 degree.
2) When core is in short-circuit (Max. 5s), the tempeture should not exceed 160 degree.
3) While installation the ambient tempeture should not be lower than o degree, and bending radius should not be less than 10 times of outer diameter.
Model, name and application
Model |
Name |
Main Application |
|
V V VLV |
PVC Insulated Sheathed Power Cable |
For laying in doors, pipe and kin tunels, but unable to bear pulling force. |
|
V V22 VLV22 |
PVC Insulated steel tape armoured and PVC sheathed power cable |
For laying on in indoor, tunels and underground, able to bear pulling force and pressure |
|
V V32 VLV32 |
PVC insulated fine steel wire armoured and PVC sheathed power cable |
For laying indoor, tunels and water, bear certain axis pulling force |
|
ZR-V V ZR-VLV |
PVC insulated PVC sheathed flame retardant power cable |
For laying indoor, pipe and kin tunels, but unable |
