xlpe insulated steel tape armoured pvc sheath electric cable
1.Specificiation
pvc sheathed electric cable pvc sheathed electric cable pvc sheathed electric cable pvc sheathed electric cable.
Conductor: Copper or Aluminum, stranded
Insulation: PVC(polyvinyl chloride)
Sheath: PVC or PE
Rated voltage: 0.6/1KV
Number of cores: One, two, three, four, five.
Reliable quality,lowest price,factory direct sell,fast delivery,best and sincere service.
pvc sheathed electric cable pvc sheathed electric cable
2.Standard of products
PVC sheathed electric cable can be produced and provided according to Chinese standard GB/T12706-2002(equivalent to IEC 60502).
The factory can also manufacture pvc sheathed electric cable that are based on British Standard (BS) and other standards.
In addition,under the requirement of customers we can design and manufacture pvc sheathed electric cable that have special performance.
The products are used in fixed laying on transmission and distribution electrical lines of 50 HZ AC rated voltage up to 6 kV.
3.Specific Property for Using
1).The long-time permissible working temperature of pvc sheathed electric cable conductive core is not more than 70°C.
2).During short circuit (max permanent time is not more than 5 seconds),the max temperature of pvc sheathed electric cable conductor is not more than 165°C.
3).The difference level of laying cable is not restricted.When laying the cable,ambient temperature is not lower than 0°C.
4).Our pvc sheathed electric cable have good chemical stability, and properties of acid resistance, alkali resistance, salt resistance, oil resistance, solvent resistance and flame resistance.
5).Light weight, good bending property and easy installation and maintenance.
pvc sheated electric cable specifications pvc sheathed electric cable
Type | Name | Usage |
VV | PVC insulated PVC sheathed power cable | Can be laid at indoor, tunnel and tube. |
VLV | ||
VY | PVC insulated and PE sheathed power cable | Can be laid at indoor, tunnel tube and seriously polluted places. |
VLY | ||
VV22 | PVC insulated, steel belt armored and PVC sheathed power cable | Can be laid at indoor, tunnel tube and mining well. |
VLV22 | ||
VV23 | PVC insulated, steel belt armored, PE sheathed power cable | Can be laid at indoor, tunnel tube mining well and serious polluted places. |
VLV23 | ||
VV32 | PVC insulated, fine steel wire Armored, PVC sheathed power cable | Can be laid at indoor, underground and mining well. |
VLV32 | ||
VV33 | PVC insulated, fine steel wire Armored, PE sheathed power cable | Can be laid at indoor, underground. |
VLV33 | ||
VV42 | PVC insulated, thick steel wire Armored, PVC sheathed power cable | Can be laid at indoor, underground, mining well. |
VLV42 |
