6mm2 pv1-f 1/2 Core Solar Cable Pv Cable with UL Standard
Construction:
ITEM |
Unit |
Spec.Value |
|
Conductor |
Material |
-- |
Tinned Copper |
Construction |
NO./mm |
84/0.30±0.004 |
|
Dia.(Approx) |
mm |
3.5 |
|
Insulation |
Material |
-- |
XLPO |
Thickness |
mm |
0.8 |
|
Dia.(Approx) |
mm |
5.1 |
|
Sheath |
Material |
-- |
XLPO |
Thickness |
mm |
0.8 |
|
Dia.(Approx) |
mm |
7.1 |
|
Color |
-- |
Red&Black |
|
Weight |
kg/km |
110 |
|
Characteristics:
Rated Voltage |
AC 0.6/1kV;DC 1.8kV |
Ambient Temperature |
-40~90℃ |
Max. Temperature at Conductor |
120℃ |
Max. Conductor Resistance at 20℃ |
3.39Ω/km |
Th permitted short-circuit-temperature(5s) |
200℃ |
Weathering/UV resistance |
PASS |
Flame Test |
IEC 60332-1 |
Rated Current |
70A |
Company Information
Henan Huaxing Wires & Cables Co., Ltd, a professional wires and cables manufacturer in China. we support to offer many kinds of wires and cables, such as xlpe/pvc electrical cable, control cable, aerial cable, ABC, AAC, AAAC, ASCR cables, and XLPO/PVC Solar PV Cable etc.
1. Factory: 67,000 square meters, available for OEM;
2. Lead time: 5-7 working days after payment received;
3. Authentication: UL,TUV;
4. Payment terms: T/T, L/C;
5. Guarantee: 31 years;
6. QC inspection: Strict inspection before delivery;
After-sales Service:
1. All our cables will be tested well in production and before delivery.
2. Please contact us if any problem, we will respond within 24 hours.
Specifications
solar cable 1, IEC, ASTM, DIN, BS VDE, UL, GOST,SAS standard.
2,TUV, ISO, CCC, CQC certification approved. 8 Years Experience of OEM
