Home > Products > Compression Testing Machine > YES 2000 KN 200 TON concrete cubes cylinders and blocks compression strength test machine
YES 2000 KN 200 TON concrete cubes cylinders and blocks compression strength test machine
- 400 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Brand Name: | HST | Place of Origin: | Shandong, China | Model Number: | YES-2000 |
Power: | Electronic | Usage: | Compression Testing Machine |
Product Description
YES 2000 KN 200 TON concrete cubes cylinders and blocks compression strength test machine
1.Application:
YES-2000 Digital Display Compression Testing Machine mainly used for Concrete Cube and other
material compression resist testing.
Widely used in metallurgy, building materials, space flight and aviation, colleges and universities,
R&D institution lines. The test operation and data processing meets standard requirements.
2.Standards:
GB/T, ISO, ASTM, DIN, JIS, etc.
3.Main Specifications:
Model | YES-2000 |
Max. Load | 2000 kN |
Class | 1 Class |
Testing Space Regulating Way | Manual Ball Screw Adjust |
Control Way | Manual Control Load Way |
Oil Source Control Cabinet Structure Form | One-piece Bench Oil Source Control Cabinet |
Range Of Test Force | 4% ~100% FS |
Indicating Value Accuracy | ±1% |
Piston Stroke | 50mm |
The Largest Spacing Of Upper And Lower Pressure Plate | 320mm |
The Largest Spacing Of Two Columns | 270mm |
Pressure Plates Size | 250*250mm(L*W) |
Display | LCD Digital Display |
The Host Dimension | 900×400×1150mm |
Power Supply | 1KW/AC380V |
Weight | 750 KG |
YAW-2000D Computer Control YES-300 Digital Display YES-2000D Digital Display
Compression machine for strength tests on concrete cubes cylinders and blocks (YES 2000 KN 200 TON )
Compression machine for strength tests on concrete cubes cylinders and blocks (YES 2000 KN 200 TON )
Compression machine for strength tests on concrete cubes cylinders and blocks (YES 2000 KN 200 TON )
1.Shipping & delivery: It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
2. Machine'Packaging: Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
One year guarantee of the whole machine
24 hours techonical support by e-mail
calling or door-to-door service
