Cement Concrete Compression Testing
Jinan Hensgrand Instrument Co., Ltd has the self-management import and
export right.All of our testing machines through the EU CE Certificate.
YE-3000B Cement Concrete Compression Testing
Machine Price
1.Functions And Application:
1.1.Adopting manual control, hydraulic loading, electronic measurement,
computer display and data auto processing,it can perform compression
test for metallic and nonmetallic materials.
1.2.Controlled by oil inlet and oil outlet valves,easy operation,with attractive
appearance;
1.3.Four columns,underneath type oil cylinder,easy for installation,with good
stability.
1.4.With reserved interface for connection with internet or computer,used for
upgrading;
1.5.Equipped with accessories,it can perform compression tests for other
materials.
2.Main Technical Parameters:
No. |
Items |
Technical Parameters |
1 |
Max. Test Force (KN) |
3000 |
2 |
Measuring Range Of Test Force (KN) |
2%-100%FS |
3 |
Accuracy Of Indicating Value |
≤±1% |
4 |
Max. Compression Space (mm) |
0-350 |
5 |
Distance Between Two Columns (L*W) mm |
500*400 |
6 |
Size Of Spherical Upper Platen (mm) |
Diam.300 |
7 |
Size Of Square Lower Platen (mm) |
400*400 |
8 |
Max. Stroke Of Pistion(mm) |
150 |
9 |
Loading Rate |
0-40KN/s, adjustable |
10 |
Dimension Of Main Machine (L*W*H) mm |
700*600*1800 |
11 |
Dimension Of Control Cabinet (mm) |
570*480*1230 |
12 |
Weight (kg) |
About 1200 |
4.Different Kinds Of Compression Testing Machines:
