HNP-2000 Drain-pipe Internal Water Pressure Testing Device
Jinan Hensgrand Instrument Co., Ltd has the self-management import and
export right.All of our testing machines through the EU CE Certificate.
HNP-2000 Drain-pipe Internal Water Pressure Testing Device
1.Application:
Concrete and reinforced concrete drainage tube pressure test device is
designed and made according with standard "Concrete And Reinforced
Concrete Drainage Tube" (GB/T 11836-99, "Concrete And Reinforced
Concrete Drainage Tube Test Method"(GB/T 16752-2010).
Adopt horizontal structure,mainly used in the internal pressure test of the
concrete and reinforced concrete drain tubes.
2.Main Technical Parameters:
Pressure Display Way | Pressure Meter |
Pressure Gauge Scale Value | 0.005MPa |
Water Adding Way | Lift>16m Water Pump |
Max Pressure | 0.16MPa |
Fastening Way | Bolt-up |
Sealing Method | Slab Rubber Seal(Special Way Seal) |
Dimension | 4000×2950×2950mm |
Weight | 2900kg |
Applicable Pipe Size | ≤Φ2000m(Φ2000-3000mm Custom-made ) |
Pressure Sequence | Plate to test tube pad good, lining board clamping. Switch on the pump pressure, until provisions pressure. Drain off with the most automatic pumping function, the tube water can take back to the reservoir. |
4.Different Kinds Of Compression Testing Machines:
