Home > Instruments & Meters > Test Instrument > Test Machine > Metal Materials JBS 300J Charpy Impact Tester
Metal Materials JBS 300J Charpy Impact Tester
US$ 6,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HST
Place of Origin:
Shandong, China
Model Number:
JBS-300C
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
The Impact Test Specimen Gap Hydraulic Broaching Machine VU-2YUS$ 700 - 1,000MOQ: 1 Set -
Pendulum Charpy Impact Testing Machine for Metal MaterialsUS$ 1,300 - 1,500MOQ: 1 Set
-
JBW 300B Computer Display Impact Testing Machines for MetalUS$ 5,000 - 7,500MOQ: 1 Set
-
DWC-40 Low Cost Degree Charpy Impact Test Low Temperature Cooling Bath Meter ChamberUS$ 1,500 - 1,650MOQ: 1 Set
-
High Precision Charpy Impact Test Low Temperature Cooling BathUS$ 999 - 2,199MOQ: 1 Set
Brand Name
HST
Place of Origin
Shandong, China
Model Number
JBS-300C
Power
Electronic
Metal materials JBS 300J charpy impact tester
Application
The impact testing machine is mainly used for measuring the metal material resistance performance under dynamic load, in order to determine the material properties under dynamic load.
It’s a necessary testing machine,not only used in the metallurgy,machine manufacture etc areas, but also used for the science research.
Product Display
Product features:
1One-body cast frame design of seat and column provide high stability
2Front and rear columns are symmetrical. Pendulum arm is designed of cantilever beam support, with simple structure and high machined precision.
3Apply high precision bearing with small friction. Absorbing energy without loading is less than 0.3%.
4Double reduction gear system replaces old style drive system with high efficiency and avoiding transmission failure.
5High rigid pendulum arm prevents axial and transverse vibrations.
6Exchangeable pendulum is simple to change to satisfy impact energy of 150J, 300J, 450J, 600J, 750J.
Model | JBS-300C | JBS-450C | JBS-600C | JBS-750C |
Max. impact energy(J) | 300 | 450 | 600 | 750 |
Pendulum Torque | 160.7695 | 241.1543 | 321.5390 | 401.9238 |
The distance between the pendulum shaft and impact point | 750mm | |||
Impact speed | 5.24 m/s | |||
Raised angle | 150° | |||
Round angle of the jaw | R1-1.5mm | |||
Round angle of impact edge | R2-2.5mm,R8±0.05mm | |||
Angle accuracy | 0.1° | |||
Standard specimen dimension | 10mm×10(7.5/5)mm×55mm | |||
Power supply | 3phs, 380V, 50Hz or specified by users | |||
Net Weight (kg) | 900 | |||
