Home > Electrical & Electronics > Power Supply & Distribution > Electric Power Fitting > F Class Insulation Materials Layer Laminated DMD Prepreg
F Class Insulation Materials Layer Laminated DMD Prepreg
US$ 5.3 - 6.0
MOQ: 500 Kilograms
Key Specifications
Get Latest Price
Brand Name:
HAIYING
Place of Origin:
China
Model Number:
6440
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
7 days
Related Products
-
DMD-Dacron Fabric/Polyester Film/Dacron FabricUS$ 3.8 - 4.8MOQ: 500 Kilograms -
Polyester Heat Shrink Tape for Transformer and Motor BindingUS$ 0.03 - 0.2MOQ: 10000 Meters
-
Mica Tape for VPIUS$ 11 - 13MOQ: 200 Kilograms
-
Epoxy Resin Impregnated Web Fiberglass Banding TapeUS$ 0.05 - 0.3MOQ: 10000 Meters
-
Non Alkali Glass Fiber Tape for Rotor and Motor BandingUS$ 0.03 - 0.2MOQ: 10000 Meters
Brand Name
HAIYING
Place of Origin
China
Model Number
6440
DMD Prepreg Insulating Material For Transformer
The electrical-use sort insulating prepreg combined with polyimide film and polyester fiber and impregnated with Epoxy Resin belongs to F class insulating material. They are widely used in the layer insulation of transformer, wire casing insulation and phase coil insulation of motor. The product is bright in color, high voltage resistance, even coating, complete in specifications and stable quality. It is widely used as ideal banding materials for electrical motors, transformers and lightening arresters.
Properties:
| Type | 6440 |
| Thermal class | F |
| Tensile Strength | ≥70 (Thickness0.18mm) |
| Soluble Resin Content (g/M²) | ≥45 |
| Volatile content | ≤1.5 |
| Loss of weight at calcination | 20±2 |
| Breadown Voltage(KV) | ≥7.0 (Thickness0.18mm) |
| Tensile strength before curing | ≥3.0 |
| Maximum pull while banding | ≤70(Thickness0.18mm) |
Specification:
| Type | Thickness(mm) | Width(mm) | Length(m) |
| 6440 | 0.15,0.18,0.2,0.25,0.3,0.4 | 1000/1200 | 200 |
*Special specification and package are availabe upon request
Shelf life::
| Storage temperature ºC | ≤40ºC |
| Time (day) | 360 |
Application:
