Brief introduction
GTB、GTB-H dry model test transformer mating different kinds of control system, is composed of power frequency withstand test device. It is the important part of the power frequency withstand test device.
Product features
◆Tight structure, stable and durable, low cost.
◆Connection is simple and easy to use.
◆Reliable insulation and good appearance.
Product parameters
Specification | Capacity(kVA) | Iutput voltage(V) | Output voltage(kV) | Output current(mA) | Output DC high voltage(kV) | Weight(kg) |
GYD/YDG(Z)-1.5/50 | 1.5 | 200 | 50 | 30 | 70 | 20 |
GYD/YDG(Z)-3/50 | 3 | 60 | 25 | |||
GYD/YDG(Z)-5/50 | 5 | 120 | 30 | |||
GYD/YDG(Z)-10/50 | 10 | 200 | 40 | |||
GYD/YDG(Z)-15/50 | 15 | 300 | 50 | |||
GYD/YDG(Z)-20/50 | 20 | 400 | 55 | |||
GYD/YDG(Z)-25/50 | 25 | 500 | 60 | |||
GYD/YDG(Z)-30/50 | 30 | 600 | 65 | |||
GYD/YDG(Z)-5/100 | 5 | 400 | 100 | 50 | 140 | 60 |
GYD/YDG(Z)-10/100 | 10 | 100 | 65 | |||
GYD/YDG(Z)-15/100 | 15 | 150 | 70 | |||
GYD/YDG(Z)-20/100 | 20 | 200 | 75 | |||
GYD/YDG(Z)-25/100 | 25 | 250 | 80 | |||
GYD/YDG(Z)-15/120 | 15 | 120 | 125 | 85 | ||
GYD/YDG(Z)-20/120 | 20 | 160 | 90 | |||
GYD/YDG(Z)-25/120 | 25 | 200 | 95 | |||
GYD/YDG(Z)-30/120 | 30 | 250 | 100 | |||
Cascade Transformer3/100 | 3kVA/50kV cascade 60kVA/50kV | |||||
Cascade Transformer3/150 | 3kVA/75kV cascade 60kVA/75kV | |||||
Note: can customize product according to user needs | ||||||
