Banner VS2 Series Sensor VS25EVQ photo-5
US$ 65 - 78 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
banner
Place of Origin:
China
Model Number:
VS25EVQ
Contact Supplier Request Quote Chat Now
Amri (Wuhan) System Engineering Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name banner
Place of Origin China
Model Number VS25EVQ
Usage Magnetic Sensor
Theory Current Sensor
Output Digital Sensor

Banner VS2 Series sensor VS25EVQ


VS2 Series: Emitter


Range: 1.2m max; Input: 12-24V dc


Not applicable - No outputs


Pico M8 3-pin Pigtail QD


Sensing Mode (General) Opposed

Sensing Mode (Detailed) Emitter

Housing Style Rectangular

Primary Housing Material Thermoplastic

Input/Output Discrete

Max Sensing Distance (mm) 1200

Power Supply/Supply Voltage 10-30 V dc

Connection Pigtail QD

Quick Disconnect Type M8 (Pico)

Sensing Beam Visible Red LED

Operation N/A

Min Op. Temp. (°C) -20

Max Op. Temp. (°C) 55

Output response time (ms) 1 ON/0.5 OFF

Special Feature: Intrinsically Safe No

Special Feature: Remote Teach No

Special Feature: Water Detection No

Sensing Beam Wavelength 660

Delay at Power-up (ms) 100

Repeatability (µs) 100

Number of Pins 3

IP Rating IP67

NEMA Rating NEMA 6

Max Op. Relative Humidity [%] 80% @ 50°C

Lens Material MABS

Adjustments N/A

Barrel Diameter (mm) N/A

Indicator LEDs

Opposed Mode Emitter/Receiver Emitter

Feature: Timing (Hold/Delay) No

Feature: Encapsulated No

Feature: Hazardous Area No

Feature: Audible No

DeviceNet No


Product Tags: VS25EVQ , banner sensor , VS2 Series
