Safety Light Curtains Banner LS2TP30-900Q88
Primary Housing MaterialAluminum
Safety LevelType 2
Effective Aperture AngleType 2 Per IEC 61496-2
Connector TypeM12
Defined Area Height (mm)900
Dimensions WxD (mm)25.4 x 31.8
Overall Length (mm)964
External Monitoring DeviceNo
Fixed BlankingNo
Housing FinishYellow Polyester
IP RatingIP65
Number of Pins (Receiver/Emitter)8
Operating Distance (m)0.2 - 15
Operating Voltage24 V dc +/- 20%
Operating Temperature0 to +55 deg. C; RH 95%
PL RatingN/A
Recovery TimeN/A
Reduced ResolutionNo
Resolution (mm)30
Response Time19
SIL RatingSIL2; CL2
Electrical Safety ClassIII
Scan CodeNone
Shock10g at 16ms (6000 cycles)
Short ProtectionYes
System TypeEmitter/Receiver Pair
Vibration10-55 Hz at 0.35 mm
Auxiliary OutputNo
Fault OutputNo
Housing MaterialAluminum; Zinc; Acrylic
OSSD Rating24 V dc at 0.5 A each
Supply Current140 mA max.
Trip/Latch OutputTrip
Test InputYes
