Banner Laser Sensor Q3XTBLD-Q8

Banner Laser sensor Q3XTBLD-Q8

Q3XT Series: Laser Diffuse

Range: 300 mm; Input: 10-30 V dc

Outputs: Bipolar: 1 NPN; 1 PNP

Connection: Euro M12 5-pin Integral Connector

Part No.： 91638

Sensing Mode (General) Proximity

Sensing Mode (Detailed) Diffuse/Background Suppression

Housing Style Rectangular w/M18 Mount

Primary Housing Material Nickel-Plated

Laser Classification Class 2

Small Visible Spot Laser

Input/Output Discrete

Max Sensing Distance (mm) 300

Outputs Bipolar (NPN & PNP)

Power Supply/Supply Voltage 10-30 V dc

Connection Integral QD

Quick Disconnect Type M12 (Euro)

Sensing Beam Laser

Operation Light/Dark Operate

Min Op. Temp. (°C) -10

Max Op. Temp. (°C) 50

Output response time (ms) 0.25

Special Feature: Intrinsically Safe No

Special Feature: Remote Teach Yes

Special Feature: Water Detection No

Sensing Beam Wavelength 655

Delay at Power-up (ms) 1000

Repeatability (µs) 60

Number of Pins 5

IP Rating IP67, IP68, IP69K

NEMA Rating N/A

Max Op. Relative Humidity [%] 95% @ 55°C

Lens Material Acrylic

Adjustments Teach Button

Barrel Diameter (mm) 18

Indicator LEDs

Opposed Mode Emitter/Receiver N/A

Feature: Washdown Rated Yes

Feature: Timing (Hold/Delay) Yes
